5
Planer Operation
Manual Operation
Remove Cross Feed Rope
4. Use the handles located on the operator side of the Gantry to manually control the Cross
Feed and Power Feed of the planer. See Figure 9
5-6
Belt Drive Tensioner
Knob
WMdoc082019
Pivot Point
FIGURE 7
FIGURE 8
Planer Operation
