3 Planer Assembly
Uncrating the Planer
REF PART # DESCRIPTION
PACKING LIST, MB200 SURFACE PLANER
1 Control Box Key
2 Control Box Switch Key
3 13mm Wrench
4 19mm Wrench
5 4mm Allen Key
6 6mm Allen Key
7 Cutter Head Box with T20 T Handle Wrench
8 127139 SANDING HEAD
9 127140 Head, Sanding Pad 7"
10 127141 Balance, Sanding
11 127142 Stud, Sanding
12 127199 Bolt, M5x10 Flat Head
13 127200 Bolt, M5x18 Socket Head
14 P10688 Bearing, R6-2NSL
15 Sandpaper, 40, 80, 180, 3 of each
16 Chain Assembly
17 127012 CLAMP ASSEMBLY, MB200
18 F05010-132 Nut, M8-1.25 Nylock
19 127173 Plate, Clamp
20 F05021-19 Bolt, M8-1.25x75 HH
21 127175 Bolt, 5/16-18x5 Carriage
22 127176 Nut, 5/16-18 Knob
23 127174 Clamp, Strap
24 127093 Stand
25 127163 Tube, Vacuum Hose Arm
26 127167 Rail, Long
27 127169 Rail, Short
28 127168 Plate, End Stop
29 127155 Clip Chain Retainer
30 F05011-134 Washer, M10
Bolt, M10-1.5x35mm HH Zinc
31 F05004-97
32 F05022-15 Bolt, M10-1.5x70 HH (52 Bolts Total - 28 Bolts on Shipping Brackets = 24)
33 F05023-10 Bolt, M12-1.75x110 HH
34 F05004-270 Nut, M10-1.5 Hex Nylock (52 Nuts Total - 28 Nuts on Shipping Brackets = 24)
35 F05010-209 Nut, M12x1.75 Hex Nylock Zinc
36 127165 Plate, Cover Roller
37 127180 Plate, Head Keeper
3-2 WMdoc082019
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
2
4
4
4
4
8
8
4
1
1
10
4
4
4
4
4
24
8
24
8
2
4
