User Manual for
MP180
ID-nr 2020-246-000-3
We hope that you find this new multi-
planer both useful and fun to work with.
In order to ensure smooth operation,
please consider the following.
IMPORTANT!
General
Check the planer as soon as it is
delivered. Any transport damage shall
be immediately reported to the
transport company.
* DO NOT LIFT THE DEVICE BY ITS
TABLE(S) OR OTHER
COMPONENTS.
If it needs to be lifted, it is most
appropriate to lift underneath the
machine frame.
* Do not use the table as bench
surface.
* When replacing spare parts, use only
original parts and note that all electric
components
must be installed by a professional.
The device has an electronic brake
The brake pulses during the braking
period,
which causes a pulsating sound.
The braking will continue for a few
seconds after the machine has
stopped.
Poly-V-belt cutter drive
When starting, the poly-V belt may
make a short-lasting whistling sound.
This is completely normal.
Space needs
The device needs a space of at least
2m width. The space length
requirements depend on the length of
the workpieces to be planed. The
minimum length is 3 m but it is
recommended that it is at least 4 m.
Anchoring
For maximum safety, the machine
must be anchored to the floor with
screws. Screw diameter 8-10 mm.
Storage
The machine must be placed in a dry
area, as it is not fully protected against
corrosion. If the machine is placed in a
cold area for an extended period of
time, its unprotected components, such
as tables or cutters, must be lubricated
with plenty of e.g. paraffin. It is also a
good idea to cover the device for
additional protection against corrosion.
If the machine is supposed to be
placed outdoors, its unprotected
components must be covered and
lubricated with anti-corrosive agents.
Application
The machine can be used for jointing
and planing of wood, particle board,
fibreboard etc.
Materials that are difficult to process,
such as particle board, teak, etc.,
require cemented carbide steel.
It is not allowed to plan plastics,
aluminum or other harder materials
without previous adjustments.
The machine is designed for indoor
use.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MP180 and is the answer not in the manual?

Questions and answers

Chad
July 8, 2025

What is the amp for a 3 phase wood mizer serial number mp180/p/038/2022

Summary of Contents for Wood-mizer MP180

  • Page 1 The User Manual for minimum length is 3 m but it is recommended that it is at least 4 m. MP180 ID-nr 2020-246-000-3 Anchoring We hope that you find this new multi- For maximum safety, the machine planer both useful and fun to work with.
  • Page 2 Table surfaces The machine tables are moulded in Sweden according to highest quality standards. Table surfaces are specially prepared to achieve highest precision Requirements for surroundings and best sliding properties. When new, the machine requires a run-in period The temperature in the room must be lasting until the table surfaces have high enough, so that no gloves are been slightly blankened for optimal...
  • Page 3: Caution Labels

    Compensation for measurement Do not let your hand(s) reach accuracy K = 4 dB(A) according to ISO underneath the jointer table. Let go of 3746 the workpiece before it approaches the machine frame and the planing table. Unloading Do not hold the workpiece with your hand underneath the jointer table.
  • Page 4 * Check that all knobs, screws, nuts, clamps, connector, cutter, planer * During jointing, one must never stand blades etc. are properly tightened. in line with the workpiece, as kickbacks Before starting the machine, make may occur. The following is sure that the cutter can spin freely and recommended in order to avoid that no tools are placed inside the...
  • Page 5 * During planing, the jointer guard so that the anti-kick-back guard or the should be put down towards the table feed rollers cannot hold it and cover the entire cutter. For planing of small dimensions, * Use only original parts intended for use fixtures such as pieces of wood the machine.
  • Page 6: Safety Equipment

    SAFETY EQUIPMENT The machine is equipped with a large number of safety components. Learn 52 46 about and understand these components...
  • Page 7 JOINTER GUARD and then try to pull it out. If the workpiece gets stuck Jointer guard setup in the machine, the anti-kick-back * During angle jointing, the jointer guard is working. guard must be adjusted in such a way that it lies tightly against the jointer The purpose of the anti-kick-back tables, and that the workpiece can fit guard is to prevent the workpiece from...
  • Page 8 SEPARATE FEED ENGINE As the feed is not connected to the cutter, it stops within about 1 sec., (loaded) due to low rotational input speed and low weight of rotating parts. 52 46 COVERS AND PROTECTIVE ELEMENTS The purpose of the covers and the protective elements is to protect the device and the people around it.
  • Page 9: Operation

    1 / Mount on the out-feed table of the jointer (20). Loosen the clamping rails. 5 / Before the machine is connected to Remove the tape the electric power network, make sure from the brass parts. As these are that all cutters can rotate freely and that all machine parts are firmly installed in place.
  • Page 10 Setup for planing The machine is ready for planing with no need for readjustment. * Planing thickness is set up using the planing table crank, (delivered separately). The thickness setup can be read from the scale on the machine stand. Feed a workpiece through the planer to measure it with a calliper and then adjust decentimals and centesimals using the crank scale.
  • Page 11 Setup for panel planing Profile blades of the horizontal cutter * Panel planing thickness can be adjusted using the planing table crank (delivered separately). The thickness The profile blades must always be setup can be read from the scale on mounted in pairs in the same side the machine stand.
  • Page 12 The spindles on the side cutters are 30 mm in diameter, which is a standard dimension. There is thus a large choice of cutters available. At delivery, the machine is equipped with one set of universal cutters in which profile blades or straight blades can be installed.
  • Page 13 2 pcs height 40 mm 2 pcs height 20 mm 2 pcs height 10 mm 1 pc. height 5 mm 2 pcs height 2 mm 1 pc. height 1 mm 1 pc. height 0.5 mm 1 pc. height 0.3 mm 1 pc.
  • Page 14 cutting edges. Disassembly: * Disconnect the machine from all power supply (main switch or wall plug). Make sure the machine is powerless. * Loosen the Allen screws and push Micro-adjustment of out-feed down the chip breaker. table * Unscrew the planer blade using the adjustment screws.
  • Page 15: Belt Tension

    the blade screw(s) just enough so that the blade scrapes against the gauge block. * Test the jointer and make sure that the workpiece remains rectilinear. If it does not remain rectilinear, adjust the out-feed table with the adjustment lever. See section micro-adjustment. If linearity problems still persist after these adjustments, check the level adjustment of the out-feed table vs.
  • Page 16 16 51 Table setup, planing mode. Necessity Changing the level adjustment of the tables is a serious modification of the machine's settings. Make sure that it is really necessary. The machine is factory preset, but the factory settings may be distorted due to careless transportation or high impact loads.
  • Page 17 Cutter and planing table setup 1/ Adjust the in-feed table 16 51 height 1 mm over the cutter body 2/ Loosen the bearing bracket screws (2 pcs M6 and 2 pcs M8 on each side) 3 / Place an absolutely flat block on the table in the middle point beneath the cutter.
  • Page 18 4/ Adjust each threaded lift pin (22) so * Check the V-belt tension from time to that the cutter touches the block over time. its entire length. * The motors are maintenance-free. 5/ Check the dimensions on the front What needs to be checked are cables side and the back side of the table and connectors, (machine frame) and adjust the front...
  • Page 19 1 / In-feed table 2 / Chip thickness adjustment lever for the jointer part 3 / Chip thickness locking lever for the jointer part 4 / In-feed table suspension bar 5 / Operating panel 6 / Protective cover for feed gearbox and switch 7 / Feed engine with industrial gear 8 / Tension wheel for planing table...
  • Page 20 18 / Feed chain 32 / V-belt gear cover 19 / Sprocket-wheels and feed roller 33 / Plastic cover for planing table 20 / Out-feed table sprocket-wheel 21 / Lift pin bearing washer for planing 34 / V-belt table 35 / Engine V-belt pulley 22 / Lift pin for planing table 36 / Micro-adjustment bar 23 / Planing table...
  • Page 21 49 / Lock lever 4 for guard height setup 50 / V-belt pulley, cutter 51 / Cone for chuck assembly 52 / Clamp bars 53 / Clamping device, central part 54 / Clamping device, angle part 55 / Feed roller, smooth (rear) 56 / Ball bearing, cutter 57 / Feed roller, knurled...
  • Page 22 74 / Press roller...
  • Page 23 MANÖVERPANEL ELSKÅP SÄKRING SÄKRING VIT LAMPA SPÄNNINGPÅ HUVBRYTARE HYVELMOTOR GUL/GRÖN FRÄSMOTOR GULGRÖN MATNINGSMOTOR GULGRÖN FRÅN...
  • Page 24 Jointer-Planer Combo Machine Wood-Mizer MP180, Nr MP180EH6S, MP180EB6S, MP180EA6S, meets the basic health and safety requirements of Directive 2006/42/EC. It is furthermore assured...
