Connectors

Ethernet RJ45 connector CN1

Figure 7. Ethernet RJ45 connector CN1 (front view)

Pin number
1
3
5
7

RS232 connector CN2

Figure 8. RS232 connector CN2 (front view)

Table 17. RS232 connector CN2 with ISP support

Pin number Description
1
2 RS232_RX (PB15)

Table 16. RJ45 connector CN1

Description
number
TxData+
RxData+
Shield
Shield
Pin
number
NC 6
7
DocID030511 Rev 1
Pin
Description
2 TxData-
4 Shield
6 RxData-
8 Shield
Description
Bootloader_BOOT0
NC
UM2198
