Table 21. Daughterboard extension connector CN6 (continued)
Pin Description Alternative function
10 GND
12 PC2_C
14 PC3_C
16 PA0_C
18 PA1_C
20 GND
22 PA5
24 PB2
26 PH4
28 PC5
30 GND
32 PG9
34 PA7
36 PJ4
38 PI15
40 PJ2
42 PJ5
44 PB13 ULPI_D6/USB_FS2_VBUS
46 PB12 ULPI_D5/USB_FS2_ID
48 +3V3
50 GND
52 PB10
54 PJ8
56 PJ9
58 PJ10
60 +5V

Table 22. Daughterboard extension connector CN7

Pin Description Alternative function
1 PF10
3 PC15
5 PI14
7 PI13 RGB_LCD_VSYNC
How to disconnect with function block on
-
-
-
Potentiometer
-
-
ULPI_CK
QSPI_CLK
ULPI_NXT
RMII_RXD1
-
QSPI_BK2_IO2
RMII_CRS_DV
RGB_LCD_R5
RGB_LCD_R0
RGB_LCD_R3
RGB_LCD_R6
-
-
ULPI_D3
RGB_LCD_G1
RGB_LCD_G2
RGB_LCD_G3
-
How to disconnect with function block on
Remove R286, Disconnect CN15, Remove
LED1
OSC32_OUT
RGB_LCD_CLK
DocID030511 Rev 1
UM2198
STM32H743I-EVAL board
-
-
-
Open SB43
-
-
Remove R118
-
Remove R117
Remove R39
-
Remove R33
Remove R44
Disconnect CN20
Disconnect CN20
Disconnect CN15, CN20
Disconnect CN20
Remove R104, R254
Remove R105, Open SB48
-
-
Remove R109
Disconnect CN20
Disconnect CN20
Disconnect CN20
-
STM32H743I-EVAL board
R294
Remove R17, Close SB4
Disconnect CN20
Disconnect CN20
