Table 21. Daughterboard extension connector CN6

Pin Description Alternative function
1 PC0
3 PH0
5 RESET#
7 PI11
9 PB5
11 PF8
13 PG14
15 PH3
17 PH2
19 PA4 EXT_RESET/LED3
21 PA3
23 PF9
25 PA6 GPIO_LCD_BL_CTRL
27 PC4
29 PB0
31 PB1
33 PJ3
35 PA1
37 PC3
39 GND
41 PJ1
43 PJ0
45 PB14 USART1_TX/USB_FS2_DM
47 PB15 USART1_RX/USB_FS2_DP
49 D5V
51 PB11
53 PJ7
55 PJ6
57 PG6
59 GND
2 PC1 RMII_MDC/ PDM1_D1
4 PF7
6 PH1
8 PF6
How to disconnect with function block on
ULPI_STP
OSC_IN
-
ULPI_DIR
ULPI_D7
QSPI_BK1_IO0
QSPI_BK2_IO3
QSPI_BK2_IO1
QSPI_BK2_IO0
ULPI_D0
QSPI_BK1_IO1
RMII_RXD0
ULPI_D1
ULPI_D2
RGB_LCD_R4
RMII_RX_CLK
DFSDM_DATA1
-
RGB_LCD_R2
RGB_LCD_R1
-
ULPI_D4
RGB_LCD_G0
RGB_LCD_R7
QSPI_BK1_NCS
-
Open SB38, Not to dial SW2 to the right
QSPI_BK1_IO2
OSC_OUT
QSPI_BK1_IO3
DocID030511 Rev 1
Connectors
STM32H743I-EVAL board
Remove R124
Remove R15, Close SB39
-
Remove R123
Remove R101
Remove R38
Remove R27
Remove R28
Remove R52
Disconnect CN4, Remove R296
Remove R114
Remove R32
Disconnect CN15
Remove R41
Remove R113
Remove R111
Disconnect CN20
Remove R31
Not to dial SW2 to the middle
-
Disconnect CN20
Disconnect CN20
Open SB46, SB47
Open SB49, SB51
-
Remove R109
Remove R24, Disconnect CN20
Disconnect CN20
Open SB6, Remove R19
-
Remove R36
Remove R16
Remove R26
