Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name
B4 PE1
C3 PE2
D3 PE3
D2 PE4
D1 PE5
E5 PE6
U9 PE7
T9 PE8
P9 PE9
N9 PE10
P10 PE11
R10 PE12
T10 PE13
U10 PE14
R11 PE15
G4 PF0
G3 PF1
G1 PF2
H4 PF3
J5 PF4
J4 PF5
K2 PF6
K3 PF7
K4 PF8
L4 PF9
L3 PF10
T7 PF11
R7 PF12
P7 PF13
P8 PF14
R9 PF15
T8 PG0
U8 PG1
H16 PG2
Default function
FMC_NBL1
PDM1_CK1
SAI1_SD_B
SAI1_FS_A
SAI1_SCK_A
SAI1_SD_A
FMC_D4
FMC_D5
FMC_D6
FMC_D7
FMC_D8
FMC_D9
FMC_D10
FMC_D11
FMC_D12
FMC_A0
FMC_A1
FMC_A2
FMC_A3
FMC_A4
FMC_A5
QSPI_BK1_IO3
QSPI_BK1_IO2
QSPI_BK1_IO0
QSPI_BK1_IO1
LED1
SDR_SDNRAS
FMC_A6
FMC_A7
FMC_A8
FMC_A9
FMC_A10
FMC_A11
FMC_A12
DocID030511 Rev 1
UM2198
Alternative function
-
FMC_A23/TRACECLK/
SAI_1_MCLK_A
FMC_A19/TRACED0
FMC_A20/TRACED1
FMC_A21/TRACED2
FMC_A22/TRACED3
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
