Table 31. USB Micro-B connector CN23 (front view) (continued)
Pin number Description
2
3

MEMS microphone coupon connectors CN25 and CN26

Figure 20. MEMS microphone coupon connectors CN25 and CN26 (top view)

Table 32. 2.21 MEMS microphone coupon connectors CN25 and CN26

Pin number
1
2
3
Pin number
DM 5
DP -
Description Pin number
DATA
GND
CLK
DocID030511 Rev 1
Description
GND
-
Description
4 V
DD
5 L/R
6 NC
Connectors
41/69
