Table 26. Memory connector CN12 (continued)
Pin Description
10 GND
12 PF1
14 PF0
16 PE2
SAI1_MCLK_A /TRACECLK
18 PI7
20 PI9
22 PI6
24 PD7
26 PD5
28 PD4
30 GND
32 PD1
34 PI3
36 PH15
38 PH14
40 +3.3V

microSD connector CN13

Figure 15. microSD connector (top view)

How to disconnect with function block on
Alternative function
-
A1
A0
A23/PDM1_CK1/
D29
D30
D28
NE1
NWE
NOE
-
D3
D27
D23
D22
-
DocID030511 Rev 1
Connectors
STM32H743I-EVAL board
-
-
-
Open SB11, SB15, SB57
-
-
-
-
-
-
-
-
-
-
-
-
37/69
