Table 33. STM32H743I-EVAL I/O assignment (continued)
Pin No. Pin Name
H15 PG3
H14 PG4
G14 PG5
G15 PG6
F16 PG7
F15 PG8
A10 PG9
A9 PG10
B9 PG11
C9 PG12
D9 PG13
D8 PG14
D6 PG15
J2 PH0 - OSC_IN
PH1 -
J1
OSC_OUT
N2 PH2
P2 PH3
P3 PH4
P4 PH5
T11 PH6
U13 PH7
T13 PH8
R13 PH9
P13 PH10
P14 PH11
R14 PH12
D16 PH13
B17 PH14
B16 PH15
A16 PI0
A15 PI1
B15 PI2
C14 PI3
A4 PI4
STM32H743I-EVAL I/O assignment
Default function
FMC_A13
FMC_A14 / SDR_BA0
FMC_A15 / SDR_BA1
QSPI_BK1_NCS
SAI_1_MCLK_A
SDR_SDCLK
QSPI_BK2_IO2
FMC_NE3
RMII_TX_EN
RMII_TXD1
RMII_TXD0
QSPI_BK2_IO3
SDR_SDNCAS
OSC_IN
OSC_OUT
QSPI_BK2_IO0
QSPI_BK2_IO1
ULPI_NXT
SDR_SDNWE
SDR_SDNE1
SDR_SDCKE1
FMC_D16
FMC_D17
FMC_D18
FMC_D19
FMC_D20
FMC_D21
FMC_D22
FMC_D23
FMC_D24
FMC_D25
FMC_D26
FMC_D27
FMC_NBL2
