Table 22. Daughterboard extension connector CN7 (continued)
Pin Description Alternative function
9 PC13 KEY_TAMP_1/WKUP2
11 PB8
13 PK7
15 PB3 JTDO/TRACESWO
17 PK6
19 GND
21 PK4
23 PK3
25 PG13
27 PA0
29 PJ15
31 PJ11
33 PC12
35 PA15
37 PG11
39 GND
41 PD2
43 PA13
45 PC6
47 PA10
49 D5V
51 PG7
53 PC9
55 PK0
57 PK1
59 GND
2 PC2
4 PC14
6 PI12 RGB_LCD_HSYNC
8 PA2
10 GND
12 PI8 GPIO_EXPANDER_INT
14 PB9
How to disconnect with function block on
SDIO_1_CKIN
RGB_LCD_DE
RGB_LCD_B7
-
RGB_LCD_B5
RGB_LCD_B4
RMII_TXD0
KEY_WKUP0
RGB_LCD_B3
RGB_LCD_G4
SDIO_1_CK
JTDI/CEC
RMII_TX_EN
-
SDIO_1_CMD
JTMS-SWDIO
SDIO_1_D0DIR
USB_FS1_ID
-
SAI_1_MCLK_A
SDIO_1_D1
RGB_LCD_G5
RGB_LCD_G6
-
DFSDM_CKOUT
OSC32_IN
RMII_MDIO
-
SDIO_1_CDIR
DocID030511 Rev 1
Connectors
STM32H743I-EVAL board
Remove R193
-
Disconnect CN20
Remove R60
Remove R199, Disconnect CN20
-
Remove R201, Disconnect CN20
Remove R202, Disconnect CN20
-
Remove R173, R203
Disconnect CN20
Disconnect CN20
Remove R83
Remove R61, Disconnect CN15
-
-
-
Remove R55
Remove SB58
Disconnect CN18
-
Remove SB56
-
Disconnect CN20
Disconnect CN20
-
Not to dial SW2 to the left
Remove R18, Close SB1
Disconnect CN20
Remove R47
-
Remove R185
Remove R91
