kWh measurement
MID certified
A-weighted emission
<70 dB(A)
sound pressure level
User interface
LED
Identification
RFID (NFC) Mifare 13.56 MHz
IEC 14443A
IEC 14443B
Plug & charge (through online portal)
Communication
GPRS 2G (minimal -80 dBm Vodafone partners)
backoffice 2.1 Ethernet connection CAT5/CAT6 (DHCP, TCP 443, TCP80, TCP21)
GPRS 2/3/4G with mobile router***
Communication GPRS 2G / 4G LTE Cat 1 (minimal -80 dBm Vodafone partners)
backoffice 2.2
Ethernet connection CAT5/CAT6 (DHCP, TCP 443, TCP80, TCP21)
GPRS 2/3/4G with mobile router***
Communication Smart Straight RJ12 (6P6C) wired CAT5 (max 20 m) - DSMR > 4.0
Meter
Backoffice protocol OCPP protocol
Stand-by consumption 3-5 W
Operating temperature -30 °C to +50 °C
range
Operating humidity 5% to 95%
range
Operating air pressure 860 hPa to 1060 hPa
range
Maximum socket
1.5 meter above ground
mounting height
Advised socket
1 meter above ground
mounting height
Mounting orientation Vertical and upright position only
Function for ventilation Not supported
according to IEC-
61851
Maximum length of 8 meters
tethered cable
Thickness of tethered
16 mm
cable
* The maximum charge capacity of the charge point depends on several factors. This includes; local rules &
regulations, the type of EV, the grid connection at your location and the electricity usage of your building
** Contact NewMotion for changing charge capacity
*** Contact NewMotion for further information: +44 20 3868 1036 and press option 1
