9.1

Technical data

Technical data
Model
Size (w x d x h)
Weight
Input voltage
Electric current
Power consumption
Fuses
RS232-Interface (labeled "com")
RS232-Interface (labeled "display")
CAN with high-power-contacts (labeled
"module 1")
Standard-CAN (labeled "module 2")
9
Supply voltage (labeled "power")
DC-Output
Working temperature
Humidity
Altitude
Emission sound pressure level at workstation
Table 9.1: Technical data of the MultiMACS Cell24 Separator.
80
Specification
MultiMACS Cell24 Separator
230 mm x 435 mm x 230 mm (9.1" x 17.1" x 9.1")
11 kg
100–240 V~, 50/60 Hz
3.5 A max.
200 W
T3.15AH250V, 5×20 mm
Pin 1, 4, 6, 7, 8, 9: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: GND
Pin 1, 6, 7: NC
Pin 2: RXD
Pin 3: TXD
Pin 4: PGM_MODE
Pin 5: GND
Pin 8: RTS
Pin 9: 5 V
Pin 3, 4, 5: NC
Pin A1: 24 V
Pin A2: GND
Pin 1: CAN_L
Pin 2: CAN_H
Pin 1, 4, 5, 8: NC
Pin 2: CAN_L
Pin 3, 6: GND
Pin 7: CAN_H
Pin 9: 24 V
Pin 1: mains voltage
Pin 2: mains voltage
Pin 3: protection conductor
Module 1 24 VDC / 8 A
Module 2 24 VDC / 0.315 A
RS232 5 V / 0.75 A
15–30 °C
0–85% relative humidity, non-condensing
max. 2,000 m
<70 dB(A)
