4.4

Buffer volumes

Apply the following buffer volumes according to the column type and workflow.
Column type
Multi-24 Column Block
LS Column
LD Column
Whole Blood Column
Table 4.4: Buffer volumes required for different column types.
4.5

Large sample volumes

When exceeding a sample volume of 5 mL, load the sample in two steps onto the column. Two 44.0 mm deep
well plates are required for the collection of equilibration buffer, flow through, and wash. Alternatively, use a
88.0 mm deep well plate.
4
1 Apply the first 5 mL of the sample and let it run through.
2 Tap MOVE BACK .
3 Exchange the deep well plate after movement of the MultiMACS Cell24 Magnet.
4 Tap OK to proceed with sample loading.
Make sure that the column reservoir is empty before applying new buffer or samples.
4.6

Magnetic labeling

For details regarding magnetic labeling, follow the instructions in the MACS Cell Separation Reagent data sheet.
58
Equilibration Wash
1×2 mL 3×1 mL
1×3 mL 2×2 mL
1×2 mL 2×1 mL
1×3 mL 2×2 mL
Elution
1×1 mL
1×4 mL
1×3 mL
1×4 mL
