Accessories; Consumables; Assembly For Benchtop Use - Miltenyi Biotec MultiMACS Cell24 Separator Plus User Manual

2.1.2

Accessories

Product
MultiMACS 5 mL Tube Rack, 1 piece
MultiMACS 12× Single-Column Adapter LS, 1 piece
Table 2.2: MultiMACS Cell24 Separator Plus accessories.
2.1.3

Consumables

Product
Multi-24 Column Block, 1 piece
2
Multi-24 Column Blocks, 8 pieces
LS Columns, 25 pieces
LD Columns, 25 pieces
Whole Blood Column Kit, 1 piece
24-well Deep Well Plates, 2x2 pieces
Single-well Deep Well Plates, 4 pieces
2-well Deep Well Plates, 4 pieces
3-well Deep Well Plates, 4 pieces
4-well Deep Well Plates, 4 pieces
Deep Well Plate Lids, 8 pieces
Table 2.3: MultiMACS Cell24 Separator Plus consumables.
Use deep well plates that comply to ANSI/SBS standards (length 127.76 mm ± 0.5 mm, width 85.48 mm ±
0.5 mm). As height of the deep well plates a value of 44.0 mm is set by default. The height value can be
changed manually.
2.2

Assembly for benchtop use

Leave a space of at least 20 cm distance above the MultiMACS Cell24 Separator Plus to ensure that the
instrument is able to tilt backwards, thus minimizing damage. If an object has been accidentally placed
under the down-moving MultiMACS Cell24 Magnet, the physical resistance of the object causes the
instrument to tilt backwards similar to a hydraulic jack.
1 Unpack all components.
2 Place the MultiMACS Cell24 Separator on a clean, stable, and flat laboratory bench. For sterile conditions
place the instrument in a laminar flow cabinet.
3 Lift the front side of the instrument and attach the Tip-Touch Plate.
44
Order no.
130-095-331
130-108-816
Order no.
130-095-692
130-095-691
130-042-401
130-042-901
130-093-545
130-110-500
130-114-966
130-120-010
130-120-009
130-120-008
130-120-007
