Technical data
Model
Size (w x d x h)
Weight
Input voltage
Electric current
Power consumption
RS232-Interface (labeled "RS232/Display")
CAN with high-power-contacts (labeled
"MultiMACS")
Display-Interface (labeled "RS232/Display")
USB-Interface (labeled "USB")
Level-Detection (labeled "sensor Bottle")
Power supply (labeled "Power In")
DC-Output
Working temperature
Humidity
Altitude
Emission sound pressure level at workstation
Table 9.2: Technical data of the MACS Elution Station.
Specification
MACS Elution Station
114 mm x 265 mm x 233 mm (4.5" x 10.4" x (9.2")
4.6 kg
24 V
0.875 A
21 W
Pin 1, 4, 6, 7, 8: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: 5 V
Pin 9: GND
Pin 4, 5: NC
Pin A1: 24 V
Pin A2: GND
Pin 1: CAN_L
Pin 2: CAN_H
Pin 3: GND
Pin 1, 4, 6, 7, 8: NC
Pin 2: RXD
Pin 3: TXD
Pin 5: GND
Pin 9: 5 V
Pin 1: 5 V
Pin 2: D-
Pin 3: D+
Pin 4: GND
Inner Contact: LIQUID-DETECT-SIGNAL
Outer Contact: GND
Pin 1,2,4: GND
Pin 3, 5: 24 V
RS232 5 V / 0.4 A
15–30 °C
0–85% relative humidity, non-condensing
max. 2,000 m
<70 dB(A)
