Lubricating The Connecting And Socket Pins - Manitowoc GROVE GMK4090 Maintenance Manual

8.14.5
Grease, tools
Check
Lubrication
Maintenance manual
GMK4090

Lubricating the connecting and socket pins

Lubricating Designation
grease
DIN 51502
Grease KP - 1K - 50
– Brush.
Depending on the equipment, the superstructure can have various connect-
ing pins and socket pins such as:
– Locks and supports on the covers
– Hinges on the crane cab's front and the rear window
– Retaining rods for the rope discs at the head of the main boom.
•
Check the pins for wear such as rust, deformation, broken clips, chains
and pin-type keepers.
•
If the pins are damaged, have them replaced by
an authorised GROVE dealer or your qualified repair crew.
•
Use only authentic replacement pins.
•
Clean the pins.
•
Lubricate the pins with a brush.
Specifications
acc. to Classification
DIN 51825
3 302 649 en
Maintenance work on the superstructure
8.14 Other maintenance work
GROVE part no.
03233369
Manitowoc Crane Care
M 12
or
8 - 83
