Nortel Secure Router 4134
Installation — Hardware
Components
Release: 10.1
Document Revision: 02.01
www.nortel.com
NN47263-301
323248-B
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Secure Router 4134 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nortel Secure Router 4134

Summary of Contents for Nortel Secure Router 4134

  • Page 1 Nortel Secure Router 4134 Installation — Hardware Components Release: 10.1 Document Revision: 02.01 www.nortel.com NN47263-301 323248-B...
  • Page 2 Nortel Networks. Except as expressly authorized in writing by Nortel Networks, the holder is granted no rights to use the information contained herein and this document shall not be published, copied, produced or reproduced, modified, translated, compiled, distributed, displayed or transmitted, in whole or part, in any form or media.

  • Page 3: Table Of Contents

    RoHS Directive Compliance Statement 12 WEEE Directive Compliance Statement 13 Safety messages 13 Notices 13 Cautions and warnings for the Secure Router 4134 14 Foreign Exchange Station (FXS) Interface Modules 15 Foreign Exchange Office (FXO) Interface Modules 16 Personal safety and equipment protection 16...
  • Page 4 Navigation 23 Power supply units 23 Fan tray 25 Interface modules for the Secure Router 4134 26 T1/E1 Small Module 27 ISDN BRI S/T and ISDN BRI U Small Modules 29 Serial Small Module 32 FXS Small Module 35...
  • Page 5 Installing or removing an internal PVM 76 Installing the internal PVM 77 Removing the internal PVM 80 Replacing the DIMM in the Secure Router 4134 82 Prerequisites 83 Installing or removing the DIMM on the Mediation Server Module for OCS 84...
  • Page 6 Power cord warning statement 121 Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 7: Secure Router 4134 Regulatory Information And Safety Precautions

    International Regulatory Statements of Conformity This is to certify that the Nortel Secure Router 4134 equipment was evaluated to the international regulatory standards for electromagnetic compliance (EMC) and safety and were found to have met the requirements for the following international standards: •...

  • Page 8: Tia-968-A

    CE marking statement (Europe only) EN 55022 statements This is to certify that the Nortel Secure Router 4134 equipment is shielded against the generation of radio interference in accordance with the application of Council Directive 2004/108/EC. Conformity is declared by the application of EN 55022 Class A (CISPR 22).

  • Page 9: European Union And European Free Trade Association (Efta) Notice

    “Translations of safety messages” (page 117). EN 55024 statement This is to certify that the Nortel Secure Router 4134 is shielded against the susceptibility to radio interference in accordance with the application of Council Directive 2004/108/EC. Conformity is declared by the application of EN 55024 (CISPR 24).

  • Page 10: Bsmi Statement (Taiwan Only)

    National Safety Statements of Compliance EN 60950 statement This is to certify that the Nortel Secure Router 4134 equipment is in compliance with the requirements of EN 60950 in accordance with the Low Voltage Directive. Additional national differences for all European Union countries have been evaluated for compliance.

  • Page 11: Nom Statement (Mexico Only)

    Méxicana (NOM): Exporter: Nortel Networks, 5400 Hellyer Ave, San Jose, CA 95138 USA. Importer: Nortel Networks de México, S.A. de C.V. Avenida Insurgentes Sur #1605 Piso 30, Oficina Col. San Jose Insurgentes Deleg-Benito Juarez México D.F. 03900 52 5 480 2100...

  • Page 12: Denan Statement (Japan/Nippon Only)

    12 Secure Router 4134 regulatory information and safety precautions 52 5 480 2100 Tel: 52 5 480 2199 Fax: Embarcar a: Nortel Secure Router 4134: • PS-SR4K-660W-AC-POE 100-240V ~ 10A/5A 50/60 Hz • PS-SR4K-250W-AC 100-240V ~ 5A/3A 50/60 Hz •...

  • Page 13: Weee Directive Compliance Statement

    This section describes the precautionary notices you find in this document. This section also contains precautionary notices that you must read for safe operation of the Nortel Secure Router 4134 and safe operation. Notices Notice paragraphs alert you about issues that require your attention. The following paragraphs describe the types of notices used in this guide.

  • Page 14: Cautions And Warnings For The Secure Router 4134

    The Lithium battery in this product is part of a non-volatile memory device and will retain data for 10 years in the absence of power. Nortel does not consider the lithium battery in this unit a field replaceable or serviceable part and should not be accessed by the customer.

  • Page 15: Foreign Exchange Station (Fxs) Interface Modules

    FXS interface modules. TIP must connect to TIP and RING must connect to RING. FXS ground start does not work if polarity is reversed. ATTENTION Nortel does not support FXS port connections leaving the building. Use FXS connections for intra-building purposes only. WARNING The 2- and 4-port FXS interface modules have a ring signal generator that is a source of hazardous voltage.

  • Page 16: Foreign Exchange Office (Fxo) Interface Modules

    FXO interface modules. TIP must connect to TIP and RING must connect to RING. ATTENTION For connections that pass outside the building in which the Secure Router 4134 resides, you must connect FXO ports through an approved network termination unit that has integrated circuit protection.

  • Page 17: Cables And Connectors Protection

    For example, ensure you connect LAN cables and connectors to LAN ports on the Secure Router 4134. • Support cables to prevent stress on the connectors. If you have a high-density cable configuration, use an appropriate cable management system to relieve stress on the cables.
  • Page 18 18 Secure Router 4134 regulatory information and safety precautions Place modules on an appropriate antistatic material when you replace hardware. Use an ESD pad or antistatic packaging. ATTENTION Some antistatic packaging is effective only on the inside of the package.

  • Page 19: New In This Release

    New in this release The following section details what’s new in Nortel Secure Router 4134 Installation — Hardware Components for Release 10.1. Features See the following sections for information about feature changes: • “Interface modules” (page 19) Interface modules Secure Router 4134, Release 10.1, introduces six new external interface modules: •...
  • Page 20 20 New in this release Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 21: Introduction

    This installation guide provides basic instruction on how to install and replace the hardware components for the Secure Router 4134. Prerequisites • The installation of the Secure Router 4134 in the equipment rack is complete. Navigation • “Nortel Secure Router 4134 hardware components fundamentals”...
  • Page 22 22 Introduction Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 23: Nortel Secure Router 4134 Hardware Components Fundamentals

    • 660 W AC (410 W available for PoE) • 250 W DC The Secure Router 4134 has two slots for power supply units. You can install single or dual power supply modules in any of the following configurations: •...
  • Page 24 24 Nortel Secure Router 4134 hardware components fundamentals • one standard AC and one PoE AC input module • one or two DC modules • one AC (standard or PoE) and one DC module CAUTION As a general safety precaution, be sure to provide DC power through a circuit breaker on the equipment rack.

  • Page 25: Fan Tray

    Fan tray The Secure Router 4134 has four fans in the fan tray assembly. The Secure Router 4134 checks the fan tray for faults every 15 seconds, and checks the temperature in the chassis every 2 minutes. The fan speed adjusts based on the chassis temperature.

  • Page 26: Interface Modules For The Secure Router 4134

    You can access the fan tray from the rear panel of the Secure Router 4134. The following figure shows the location of the fan tray in the chassis, and indicates air flow through the chassis. The Secure Router 4134 ships with the fan tray installed. CAUTION Risk of equipment damage The fan is essential for maintaining optimal system operating temperature.

  • Page 27: T1/E1 Small Module

    ATTENTION Slot 2 of the Secure Router 4134 supports only one port of any WAN data Small Module. If you install a 2-port Small Module in Slot 2, and use the Small Module for data connections, one port only is functional (port 1).
  • Page 28 (supports 31 timeslots with a line data rate of 2.048 Mbps). In voice mode, the T1/E1 Small Module supports Channel Associated Signaling (CAS) to provide the Secure Router 4134 with connections to the Public Switched Telephone Network (PSTN). The T1/E1 Small Module supports CAS only when you configure the module for T1 connections.

  • Page 29: Isdn Bri S/T And Isdn Bri U Small Modules

    Interface modules for the Secure Router 4134 29 Table 2 Cable and connectors Port Recommended Minimum Maximum Connector cable type cable length cable length T1/E1 RJ45 T1: Dual twisted None T1: DSX1 pair, 100 ohm, (interior) from 0 CAT3 or better to 655 ft.
  • Page 30 Module slots on the Secure Router 4134 chassis. ATTENTION Slot 2 of the Secure Router 4134 supports only one port of any WAN data Small Module. If you install a 2-port Small Module in Slot 2, and use the Small Module for data connections, one port only is functional (port 1).
  • Page 31 Interface modules for the Secure Router 4134 31 Figure 5 2-port ISDN BRI S/T Small Module The following figure shows the 2-port ISDN BRI U Small Module. Figure 6 2-port ISDN BRI U Small Module Table 4 Cable and connectors...

  • Page 32: Serial Small Module

    Module slots on the Secure Router 4134 chassis. ATTENTION Slot 2 of the Secure Router 4134 supports only one port of any WAN data Small Module. If you install a 2-port Small Module in Slot 2, and use the Small Module for data connections, one port only is functional (port 1).
  • Page 33 Figure 8 2-port Serial Small Module You configure each serial port using the Command Line Interface (CLI). The Secure Router 4134 detects any configuration mismatch with connected cables and signals an error with a red LED. Table 6 Cable and connectors...
  • Page 34 Green: The link or channel is active and receiving a valid signal When you power on the Secure Router 4134 with a serial configuration, the serial interface software polls the port hardware status to ensure the connected cable matches the port configuration.

  • Page 35: Fxs Small Module

    You can install the 2- and 4-port FXS Small Modules in any of the Small Module slots on the Secure Router 4134 chassis. You can also install the FXS Small Modules in the Voice Carrier Medium Module, which you can install in any Medium Module slot.
  • Page 36 36 Nortel Secure Router 4134 hardware components fundamentals Table 10 Cable and connectors Port Recommended Minimum cable Loop length Connector cable type length RJ11 24 AWG Catego 5500 ft (1676.4 ry 5 twisted pair cable ATTENTION Ensure you use straight cables with FXS modules. TIP must connect to TIP and RING must connect to RING.

  • Page 37: Fxo Small Module

    You can install the 2- and 4-port FXO Small Modules in any of the Small Module slots on the Secure Router 4134 chassis. You can also install the FXO Small Modules in the Voice Carrier Medium Module, which you can install in any Medium Module slot.
  • Page 38 38 Nortel Secure Router 4134 hardware components fundamentals Figure 12 4-port FXO Small Module The following table lists the connectors and cable to use with the 2- and 4-port FXO Small Modules. Table 12 Cable and connectors Port Connector Recommended...

  • Page 39: T1/E1 Medium Module

    Interface modules for the Secure Router 4134 39 Table 13 Module LEDs (cont’d.) Description LINK/STAT 3 Status of interface 3: (applicable to • Red: The port is not configured 4-port module • only) Green: A call is in progress •...

  • Page 40: Hssi Medium Module

    40 Nortel Secure Router 4134 hardware components fundamentals Table 14 Cable and connectors Port Recommended Minimum Maximum Connector cable type cable length cable length T1/E1 RJ45 T1: Dual twisted None T1: DSX1 pair, 100 ohm, (interior) from 0 CAT3 or better to 655 ft.

  • Page 41: Ct3 Medium Module

    Interface modules for the Secure Router 4134 41 Table 16 Cable and connectors Port Recommended Minimum Maximum Connector cable type cable length cable length High-speed serial 50-pin HSSI HSSI null modem None 50 ft (15 m) cable Table 17 Module LEDs...

  • Page 42: Ds3 Medium Module

    42 Nortel Secure Router 4134 hardware components fundamentals Table 18 Cable and connectors Port Connector Recommended Minimum Maximum cable type cable length cable length Two BNC Two 75 ohm None 450 ft (137.16 m) connectors — unbalanced coax one for transmit...

  • Page 43: Gbe Medium Module

    Interface modules for the Secure Router 4134 43 Table 20 Cable and connectors Port Recommended Minimum Maximum Connector cable type cable length cable length Two BNC Two 75 ohm None 450 ft (137.16 m) connectors — unbalanced coax one for transmit...
  • Page 44 44 Nortel Secure Router 4134 hardware components fundamentals Figure 17 10-port GbE Medium Module Table 22 Cable and connectors Port Recommended Minimum Maximum Connector cable type cable length cable length 10Base-T (full- RJ45 EIA Category None 328 ft (100 m)

  • Page 45: Fe And Fe/Poe Medium Module

    Interface modules for the Secure Router 4134 45 Table 23 Module LEDs Description STAT General module status: • Off: No power available to the module • Yellow: Out of service, or failed to initiate • Green: Power on and the module is operational 10/100/1000 LEDs are integrated into each port.

  • Page 46: Mediation Server Module For Ocs

    46 Nortel Secure Router 4134 hardware components fundamentals Figure 19 24-port FE/PoE Medium Module ATTENTION You must install the Secure Router 4134 PoE power supply to take advantage of the PoE capabilities. Table 24 Cable and connectors Port Connector Recommended...
  • Page 47 The module ships with one DIMM memory module installed (1 GB). You can install a second DIMM memory module, if necessary. You must remove the Mediation Server Module from the Secure Router 4134 to install or remove DIMM memory modules.

  • Page 48: Voice Carrier Medium Module

    • Green, blinking: There is activity at the Compact Flash card Voice Carrier Medium Module The Voice Carrier Medium Module is a hot-swappable module. The Secure Router 4134 supports the following voice-type Small Modules: • 2- and 4-port FXO •...

  • Page 49: Gbe Large Module

    Interface modules for the Secure Router 4134 49 Figure 21 Voice Carrier Medium Module CAUTION If you do not install a module in a slot, keep the metal cover plate in place over the slot. Removing the cover plate impedes airflow and proper cooling of the unit.
  • Page 50 50 Nortel Secure Router 4134 hardware components fundamentals Figure 22 44-port GbE Large Module This module is oversubscribed and provides a 4:1 blocking ratio. The total available bandwidth at all of the ports (44 Gbps) is four times the available routing bandwidth.

  • Page 51: Internal Hardware Components

    The following figure shows the internal hardware components that are field serviceable. For information about locating and removing the service panel to access the internal hardware components, refer to Nortel Secure Router 4134 Installation — Chassis (NN47263-300). Nortel Secure Router 4134 Installation —...

  • Page 52: Ddr So-Dimm

    You cannot hot swap internal components. DDR SO-DIMM The Secure Router 4134 has one SO-DIMM slot. The slot supports a DDR RAM module of either 512 MB or 1 GB. The router ships with a 1 GB DIMM installed.

  • Page 53: Vpn/Ipsec Module

    Figure 24 Internal VPN/IPSec module Internal PVM You must install the internal PVM in the Secure Router 4134 chassis to use the voice-related modules and features. The following figure shows the PVM in relation to the DDR SO-DIMM. Nortel Secure Router 4134 Installation —...
  • Page 54 ATTENTION You cannot enable the management port on the rear of the Secure Router 4134 (Ethernet 0/0) if you have a PVM installed (this is related to hardware design). Ensure you use Ethernet 0/1, 0/2, 0/3, or 0/4 for management if you use a PVM in the router.

  • Page 55: Internal System Compact Flash

    CF0. Hot swapping hardware components This section lists the Secure Router 4134 hardware components that you can service while the system is powered. The following table lists parts that are operator replaceable, as well as the hot swapping capabilities and limitations for each part.
  • Page 56 56 Nortel Secure Router 4134 hardware components fundamentals Table 31 Hot swapping capabilities for the Secure Router 4134 (cont’d.) Component Hot swap Limitations capable — All external cables DDR SO-DIMM CAUTION Do not open the Secure Router 4134 service access panel while the unit is powered.

  • Page 57: Installing Secure Router 4134 Hardware Components

    Installing Secure Router 4134 hardware components The Secure Router 4134 ships with the fan tray installed, as well as the power supply unit or units that you ordered. This section contains instructions for installing hardware components, as well as instructions for replacing a fan tray, power supply unit, and internal components.
  • Page 58 Slot numbering on the Secure Router 4134 A slot numbering legend is printed directly above the chassis SFP Ethernet ports (ports 0/3 and 0/4) on the front panel of the Secure Router 4134. The legend shows how slots are numbered on the Secure Router 4134. The following figure shows the slot numbering legend.

  • Page 59: Prerequisites

    Installing the interface modules 59 Figure 27 Slot numbering legend printed on the Secure Router 4134 Slots 1–4 are Small Module slots. Slots 5–7 are Medium Module slots. If you insert a Large Module, it spans slots 6 and 7. In this case, the Large Module is identified in the Command Line Interface (CLI) as slot 6.

  • Page 60: Installing A Medium Module

    60 Installing Secure Router 4134 hardware components Nortel recommends that you power down the Secure Router 4134 if you are installing an interface module in a slot in which you have not previously installed that module type. If you are working with 2- or 4-port FXS or FXO Small Modules, ensure you read the safety messages related to the FXS and FXO interface modules.

  • Page 61: Installing A Large Module

    Ensure the levers on the module are flush with the front panel of the Secure Router 4134. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 62: Installing A Small Module In The Voice Carrier Medium Module

    Installing a Small Module in the Voice Carrier Medium Module Ensure you securely install the Voice Carrier Medium Module in the Secure Router 4134 chassis before installing Small Modules in the Voice Carrier Medium Module. For instructions to install the Voice Carrier Medium Module in the chassis, see “Installing a Medium Module”...

  • Page 63: Hot Swapping Interface Modules

    ATTENTION Hot swap an interface module only if the Secure Router 4134 recognizes the card. When a card fails to initialize, the Secure Router 4134 should still recognize that the module is installed. Use the show chassis command to verify that the Secure Router 4134 recognizes that the interface module is installed.
  • Page 64 Secure Router 4134. If the interface module does not appear in the list of installed modules, see Nortel Secure Router 4134 — Troubleshooting (NN47263-700). To access the configuration mode, enter:...

  • Page 65: Connecting Power Cables

    Step Action Insert the female end of an appropriately rated AC power cord in the AC receptacle on the rear panel of the Secure Router 4134, as shown in the following figure. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard...

  • Page 66: Connecting Dc Power

    Average time to install one DC power cable: 3 minutes. CAUTION Always wear an ESD-preventative wrist strap when connecting cables or performing maintenance on a Secure Router 4134. Ensure that the wrist strap makes contact with your skin. CAUTION As a general safety precaution, ensure you provide DC power through either a fuse or DC circuit breaker with a maximum rating of 12 amps.
  • Page 67 DC power source is switched off. Loosen both terminal cover screws on the DC power supply. Remove the terminal cover to expose the terminal block. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 68 68 Installing Secure Router 4134 hardware components Insert the –48 V lead behind the –48 V terminal. Tighten the –48 V terminal to hold the lug and wire in place. The maximum tightening torque for terminal screws is 9 in-lb (1.02 N-m).

  • Page 69: Connecting The Console Port Cable

    To access the command line interface (CLI) using the rear panel console port, connect a terminal or a workstation running terminal emulation software to the Secure Router 4134 using the console cable that ships with the unit. Nortel Secure Router 4134 Installation —...

  • Page 70: Prerequisites

    --End-- Installing or replacing a power supply module The Secure Router 4134 operates with one or two AC power supply modules, one or two DC power supply modules, or one AC and one DC power supply module. You install the power supply modules at the rear of the unit.

  • Page 71: Prerequisites

    Installing or replacing a power supply module 71 Prerequisites • Ensure you have the power supply module for the Secure Router 4134. • Ensure you have a Phillips #2 screwdriver. Procedure steps to install a power supply unit Step Action...

  • Page 72: Replacing A Fan Tray Module

    72 Installing Secure Router 4134 hardware components Replacing a fan tray module The Secure Router 4134 ships with the fan tray module installed. This section contains instructions for replacing a fan tray module. Average time to install or replace a fan tray module: 1 minute.

  • Page 73: Installing The Internal Vpn/Ipsec Module

    Installing or removing the internal VPN/IPSec module 73 If you ordered the VPN/IPSec module with your Secure Router 4134, the Secure Router ships with the VPN/IPSec module installed. Average time to install the internal VPN/IPSec module: 2 minutes. CAUTION Do not open the Secure Router 4134 service access panel while the unit is powered.

  • Page 74: Removing The Internal Vpn/Ipsec Module

    Use the procedure in this section to remove a VPN/IPSec module from the Secure Router 4134. CAUTION The internal VPN/IPSec module is not hot swappable. Do not open the Secure Router 4134 service access panel while the unit is powered. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard...

  • Page 75: Prerequisites

    Procedure steps Step Action Remove the two screws at the rear of the Secure Router 4134 that hold the service access panel secure. Remove these two screws only. See the following figure. Slide the access panel toward you until it is clear of the Secure Router 4134.

  • Page 76: Installing Or Removing An Internal Pvm

    ATTENTION You cannot enable the management port on the rear of the Secure Router 4134 (Ethernet 0/0) if you have a PVM installed (this is related to hardware design). Ensure you use Ethernet 0/1, 0/2, 0/3, or 0/4 for management if you use a PVM in the router.

  • Page 77: Installing The Internal Pvm

    Procedure steps Step Action Remove the two screws at the rear of the Secure Router 4134 that hold the service access panel secure. Remove these two screws only. See the following figure. Slowly slide the access panel toward you until it is clear of the Secure Router 4134.
  • Page 78 78 Installing Secure Router 4134 hardware components Ensure the PVM slot is clear of debris. Protective tape is placed over the SO-DIMM and PVM slots during the manufacturing process; remove this tape if it is present. Holding the PVM by its edges, insert the module in the slot on the Main Board, pushing down gently, but firmly, to fully seat the module.
  • Page 79 Installing or removing an internal PVM 79 The release latches close when the PVM is properly installed. See the following figure. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 80: Removing The Internal Pvm

    80 Installing Secure Router 4134 hardware components Install the access panel onto the Secure Router 4134. Install the two screws that secure the service access panel to the Secure Router 4134. --End-- Removing the internal PVM Use the procedure in this section to remove a PVM from the Secure Router 4134.
  • Page 81 Procedure steps Step Action Remove the two screws at the rear of the Secure Router 4134 that hold the service access panel secure. Remove these two screws only. See the following figure. Slide the access panel toward you until it is clear of the Secure Router 4134.

  • Page 82: Replacing The Dimm In The Secure Router 4134

    Use the instructions in this section if you must replace the DIMM. The DIMM is not hot-swappable. Average time to replace a DIMM: 2 minutes. CAUTION Do not open the Secure Router 4134 service access panel while the unit is powered. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard...

  • Page 83: Prerequisites

    Procedure steps Step Action Remove the two screws at the rear of the Secure Router 4134 that hold the service access panel secure. The following figure shows the two screws that you must remove. Slowly slide the access panel toward you until it is clear of the Secure Router 4134.

  • Page 84: Installing Or Removing The Dimm On The Mediation Server Module For Ocs

    Mediation Server Module is not hot-swappable. Average time to replace a DIMM on the Mediation Server Module: 4 minutes. CAUTION Do not open the Secure Router 4134 service access panel while the unit is powered. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard...

  • Page 85: Installing A Dimm On The Mediation Server Module

    Average time to install a DIMM on the Mediation Server Module: 3 minutes. Prerequisites • Ensure the Secure Router 4134 is powered down. • Ensure you have a Phillips #2 screwdriver. • Ensure you have antistatic material available on which to lay the Mediation Server Module while you work.
  • Page 86 86 Installing Secure Router 4134 hardware components Support the module as you remove it from the chassis by grasping it by the edges. Ensure you place the Mediation Server Module on antistatic material if you lay it down to install a DIMM.

  • Page 87: Removing A Dimm From The Mediation Server Module

    Average time to remove a DIMM from the Mediation Server Module: 3 minutes. Prerequisites • Ensure the Secure Router 4134 is powered down. • Ensure you have a Phillips #2 screwdriver. • Ensure you have an antistatic bag or sheet available for the DIMM that you are removing.

  • Page 88: Replacing The Internal Compact Flash

    88 Installing Secure Router 4134 hardware components Always hold the module by its edges. Locate the DIMM to remove from the module. Release the latches on each end of the DIMM slot. The following figure shows the DIMM slots and the release latches.

  • Page 89: Prerequisites

    CAUTION Do not open the Secure Router 4134 service access panel while the unit is powered. ATTENTION The internal Compact Flash that ships with the Secure Router 4134 contains the system image. Prerequisites • Ensure you have a replacement Compact Flash ready to install.
  • Page 90 90 Installing Secure Router 4134 hardware components Insert the replacement Compact Flash in the slot, pushing down firmly but gently to fully seat it in the slot. --End-- Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008...

  • Page 91: Environmental Requirements

    Nortel Secure Router 4134 to authorized service personnel only. Ensure you allow 2 to 3 feet (0.61 to 0.91 m) of additional clearance around the Secure Router 4134 for access to the cable connectors on the front and rear panels.
  • Page 92 92 Environmental requirements Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 93: Interface Connector Pin Assignments

    Appendix Interface connector pin assignments The following tables describe Secure Router 4134 interface connector pin assignments. SFP connector pin assignments are not listed because they are dependent on the specific SFP module that you install. Pins that are not connected are reserved and should not be used.
  • Page 94 — Unused — — Unused — — Unused Table 37 FXO connector pin assignments (RJ11 interface) Function Not connected (N/C) Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 95 DCD+ DCD+ DCD+ RLSD DTR+ DTR+ DTR+ RTS+ RTS+ RTS+ RTS– RS– RTS– RTS– C– CTS– CS– CTS– CTS– I– Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 96 SCR+ TXC+ TXC+ TXC+ SCT+ RXC+ TXCE TXCE+ TXCE+ SCTE+ RXD+ TXD+ TXD+ DCD+ DCD+ DCD+ RLSD DTR+ DSR+ DSR+ Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 97 Open Open EIA–530 DTE Open EIA–530 DCE Open Open EIA–530A DTE Open EIA–530A DCE Open Open RS–449 DTE Open Open Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 98 SG (Signal Ground) — — — Not Used 20–23 45-48 TM (Test Mode) Input — — — SG (Signal Ground) Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 99 Data Pair 3 – BI_DB– BI_DA– Data Pair 2 – BI_DD+ BI_DC+ Data Pair 4 + BI_DD– BI_DC– Data Pair 4 – Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 100 100 Interface connector pin assignments Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 101: Serial Cable Descriptions

    Appendix Serial cable descriptions Use this section for specification information about the serial cables available for the Secure Router 4134. DTE V.35 serial cable Order code: SR0018011E6 Figure 29 DTE V.35 serial cable Table 46 DTE V.35 serial cable description...

  • Page 102: Dce V.35 Serial Cable

    No connect MODE1 MODE0 MODE3 DSR– No connect DCE V.35 serial cable Order code: SR0018012E6 Figure 30 DCE V.35 serial cable Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 103: Dte X.21 Serial Cable

    No connect MODE2 No connect MODE1 MODE0 MODE3 No connect DSR– No connect DTE X.21 serial cable Order code: SR0018013E6 Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 104 No connect No connect TXCE– No connect TXC– No connect DCD– No connect DTR– No connect MODE2 MODE1 No connect Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 105: Dce X.21 Serial Cable

    RXD– pair T– → RTS+ Twisted → RTS– pair I– ← CTS+ Twisted ← CTS– pair C– — Shield Shield Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 106: Dte Rs-449 Serial Cable

    No connect MODE3 No connect DSR– No connect DTE RS-449 serial cable Order code: SR0018015E6 Figure 33 DTE RS-449 serial cable Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 107: Dce Rs-449 Serial Cable

    — Shield Shield Shield Shield MODE2 No connect MODE1 MODE0 No connect MODE3 DCE RS-449 serial cable Order code: SR0018016E6 Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 108 ← DSR+ Twisted ← DSR– pair TR– → Twisted pair — 19, 20, 37 — Shield Shield Shield Shield Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 109: Dte Rs-232 Serial Cable

    → TXCE+ TXCE ← TXC+ ← RXC+ ← RXD+ ← DCD+ → DTR+ → RTS+ ← CTS+ ← DSR+ → Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 110: Dce Rs-232 Serial Cable

    No connect MODE1 No connect MODE0 MODE3 DCE RS-232 serial cable Order code: SR0018018E6 Figure 36 DCE RS-232 serial cable Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 111: Dte Rs-530 Serial Cable

    DSR– No connect MODE2 No connect MODE1 No connect MODE0 MODE3 No connect DTE RS-530 serial cable Order code: SR0018019E6 Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 112 CS– ← CTS+ pair ← DSR+ Twisted ← DSR– pair DM– → Twisted — pair — Shield Shield Shield Shield Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 113: Dte Rs-530A Serial Cable

    ← RXC– pair RT– ← RXD+ Twisted ← RXD– pair RD– ← DCD+ Twisted ← DCD– pair RR– → DTR+ Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 114 Twisted — pair — Shield Shield Shield Shield DTR– No connect MODE2 MODE1 MODE0 No connect MODE3 DSR– No connect Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 115: Hardware Reliability

    Secure Router 4134 hardware in terms of FIT and MTBF. ATTENTION Ensure you install the Secure Router 4134 and its components correctly and operate the unit within the intended environment under specified conditions. The failure rate and MTBF values in the following table do not include failure caused by software or erroneous human action.

  • Page 116: Battery Life Expectancy On The Mediation Server Module For Ocs

    (shutdown time) of the system in which the battery operates. To ensure that the lifetime of the battery is not exceeded, Nortel recommends that you exchange the battery every 4–5 years.

  • Page 117: Translations Of Safety Messages

    équipement dans une zone résidentielle risque de causer des interférences nuisibles, auquel cas l’utilisateur devra y remédier à ses propres frais. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 118: Qualified Service Personnel Warning Statement

    Lesen und befolgen Sie die Warnungshinweise und Anweisungen, die auf dem Produkt gekennzeichnet oder in der Dokumentation enthalten sind. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...

  • Page 119: Overcurrent Warning Statement

    Overcurrent warning statement WARNING The Secure Router 4134 relies on the building installation for overcurrent protection. Ensure that a fuse or circuit breaker no larger than 120 VAC, 15A U.S. (240 VAC, 10 A international) is used on the phase conductors.

  • Page 120: Cover Plate Warning Statement

    If you do not install a module in a slot, keep the metal cover plate in place over the slot. Removing the cover plate impedes airflow and proper cooling of the unit. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 121 Lack of a grounding path to the switch may result in excessive emissions. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 122 L’assenza di un percorso per il collegamento a terra dell’interruttore può causare un eccesso di emissioni. Nortel Secure Router 4134 Installation — Hardware Components NN47263-301 02.01 Standard 18 February 2008 Copyright © 2007, 2008 Nortel Networks...
  • Page 124 This document is protected by copyright laws and international treaties. All information, copyrights and any other intellectual property rights contained in this document are the property of Nortel Networks. Except as expressly authorized in writing by Nortel Networks, the holder is granted no rights to use the information contained herein and this document shall not be published, copied, produced or reproduced, modified, translated, compiled, distributed, displayed or transmitted, in whole or part, in any form or media.

Table of Contents
