4.4. Power Consumption

The pITX-IMX8M power consumption depends on variant used and load profile.

Table 6: Power Consumption

Power Figures SBC
iMX8 M
iMX8 M Deep Sleep
Mode
iMX8 M Idle
iMX8 M Run
pITX Peripherals
1x eDP ext.
1x LVDS
IO Voltage ext.
1x LVDS
Backlight ext.
1x HDMI ext
1x M.2 Module ext
2x USB 2.0 ext
2x USB 3.0 ext
2x CSI Cam ext.
1x FAN ext.
IMX8 M power numbers are typical values based on typical silicon at 25°C.
Power numbers distributed to external devices are max. allowed values, partially overcurrent protected.
Please refer to the NXP iMX8 M datasheets and application notes like i.MX 8M Quad Power
Consumption Measurement for further details.
44011-0208- 44011-
13-2 0408-13-4
Industrial + Industrial +
VPU VPU
not applicable
3.3 V * 1500 mA = 4950 mW
Or 5.0 V * 1500 mA = 7500
mW
12.0 V * 1500 mA = 18000 mW
Or 5.0 V * 1500 mA = 7500
mW
2 * 5.0 V * 500 mA = 5000 mW
2 * 5.0 V * 900 mA = 9000 mW
44011-0216- 44011-0416-
15-2 15-4lit
Commercial Commercial
+ VPU + VPU
200 mW
400 mW
1000 mW – 4000 mW
2000 mW – 5000 mW
3.3 V * 750 mA = 2475 mW
not applicable
not applicable
5.0 V * 50 mA = 250 mW
3.3 V * 2500 mA = 8250 mW
2 * 350 mW (e.g. OV5640)
5.0 V * 80 mA = 400 mW
