Hdmi Connector (J7); Table 31: Hdmi Mapping; Figure 24: 19-Pin Hdmi Connector - Kontron pITX-iMX8M User Manual

Pin Function
24 LVDS0_CK+
25 LVDS0_3-
26
LVDS0_3+
27 GND
28
GND
29 LVDS1_0-
30 LVDS1_0+
31 LVDS1_1-
32 LVDS1_1+
33 LVDS1_2-
34 LVDS1_2+
35 LVDS1_CK-
36
LVDS1_CK+
37 LVDS1_3-
38 LVDS1_3+
39 GND
40 GND

6.15. HDMI connector (J7)

HDMI or general connectors: connect only approved devices

Figure 24: 19-pin HDMI connector

Table 31: HDMI Mapping

Pin Function
1 HDMI_D2_+
2 GND
3 HDMI_D2_-
4
HDMI_D1_+
5 GND
6
HDMI_D1_-
7 HDMI_D0_+
8 GND
9 HDMI_D0_-
Direction
Out
Out
Out
Ground
Ground
Out
Out
Out
Out
Out
Out
Out
Out
Out
Out
Ground
Ground
Direction Description
Out
Ground TMDS Link Channel 2
Out
Out
Ground TMDS Link Channel 1
Out
Out
Ground TMDS Link Channel 0
Out
Description
LVDS channel 0, clock, positive
LVDS channel 0, lane 3, negative
LVDS channel 0, lane 3, positive
LVDS channel 1, lane 0, negative
LVDS channel 1, lane 0, positive
LVDS channel 1, lane 1, negative
LVDS channel 1, lane 1, positive
LVDS channel 1, lane 2, negative
LVDS channel 1, lane 2, positive
LVDS channel 1, clock, negative
LVDS channel 1, clock, positive
LVDS channel 1, lane 3, negative
LVDS channel 1, lane 3, positive
www.kontron.com
pITX-iMX8M – Rev. 1.1
