Mini Display Port (J14); Table 32: Mini Display Port; Figure 25: Mini Display Port - Kontron pITX-iMX8M User Manual

Pin Function
10 HDMI_D3_+
11 GND
12
HDMI_D3_-
13 HDMI_CEC
14
HDMI_AUX_-
15 HDMI_DDC_SCL
16 HDMI_DDC_SDA
17 GND
18 V_5V0_HDMI
19 HDMI_AUX_+/HPD

6.16. Mini Display Port (J14)

Figure 25: Mini Display Port

Table 32: Mini Display Port

Pin Function
1 GND
2 HOT_PLUG
3 DP0 TX0+
4 NC
5 DP0 TX0-
6 GND
7 GND
8 GND
9 DP0 TX1+
10 DP0 TX3+
11 DP0 TX1-
12 DP0 TX3-
13
GND
14
GND
Direction
Out
Ground
Out
In/Out
In
Out
In/Out
Ground
Power
In
1
Direction
Ground
In
Out
n.a
Out
Ground
Ground
Ground
Out
Out
Out
Out
Ground
Ground
Description
TMDS Clock Channel
Optional usage as Audio Return Channel
HDMI DDC Serial Clock
HDMI DDC Serial Date
Hot plug detect, optional usage as Audio Return
Channel
Description
Config 1 is not connected
Config 2 is pulled to GND
www.kontron.com
pITX-iMX8M – Rev. 1.1
// 44
