Table 3-2: Flag Pin Summary

Pin Connected
to
FLAG3 AD1881A
Reset
FLAG2 LED1
FLAG1 LED2
FLAG0 LED3
~IRQ2 SW3
~IRQ1 SW5
~IRQ0 SW4

3.5 Example Programs

Example programs are provided with the ADSP-21160 EZ-KIT Lite evaluation
system to demonstrate various capabilities of the board. These programs are
installed with the EZ-KIT Lite software and can be found in \...\VisualDSP\
211xx\EZ-KITs\ADSP-21160\Examples.
provided with each example program for more information.

3.6 Using the Flash Programmer Utility

The ADSP-21160 EZ-KIT Lite evaluation system includes a Flash Programmer
Utility. The utility allows you to program the flash on the EZ-KIT Lite board.
This utility must be installed separately from the debug software. To install the
utility, insert the EZ-KIT Lite disc and follow the steps in the installation wizard.
After the flash utility has been installed, it is available from the Tools menu in
VisualDSP++.
For more information on the Flash Programmer Utility go to the Start menu and
choose Programs\VisualDSP\Flash Programmer Help.
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Use
FLAG3 is connected directly to the reset pin of the
AD1881A audio codec. To reset the AD1881A drive
this signal low.
FLAG2-0 are connected to the LEDs. These can be
used, for example, to light an LED when a routine
completes.
~IRQ2-0 are connected to the push buttons on the
EZ-KIT Lite board and are for user input. Your
routine can monitor and execute specific code when a
button is pushed.
Please refer to the readme files
3-27
