APPENDIX A: BILL OF MATERIALS

A.1: ADDS-21160-EZLITE

This bill of materials is for the 2.5V version of the EZ-KIT Lite evaluation
system, which contains the ADSP-21160M DSP. For the bill of materials for the
ADDS-21160N-EZLITE go to section A.2.
REF QTY.
M29W040 PLCC32
1 1
FLASH-512K-X-8-3V
74LVC14A SOIC14
2 2
HEX-INVER-SCHMITT-TRIGGER
IDT74FCT3244APY SSOP20
3 1
3.3V-OCTAL-BUFFER
24.576MHZ SMT OSC005
4 1
CRYSTAL
CY7C64603-128 PQFP128
5 1
USB-TX/RX MICROCONTROLLER
MMBT4401 SOT-23
6 1
NPN TRANSISTOR 200MA
74LVC00AD SOIC14
7 1
24LC00-SN SOIC8
8 1
128 BIT SERIAL EEPROM
CY7C1019BV33-15VC SOJ32
9 1
128K X 8 SRAM
AD8532AR SOIC8
10 1
DUAL AMP 250MA
SN74AHC1G02 SOT23-5
11 1
SINGLE-2 INPUT-NOR
SN74LV164A SOIC14
12 1
8-BIT-PARALLEL-SERIAL
CY7C4201V-15AC TQFP32
13 1
64-BYTE-FIFO
12.0MHZ THR OSC006
14 1
CRYSTAL
SN74AHC1G00 SOT23-5
15 1
SINGLE-2-INPUT-NAND
MT58L64L32 TQFP100_B
16 2
64KX32-SBSRAM
LT1765 SO-8
17 1
ADJUSTABLE-3A-SWITCH-REG
40MHZ SMT OSC003
18 1
Description
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Ref. Des
U3
U7, U19
U6
Y1
U11
Q1
U5
U25
U12
U10
U16
U17
U18
Y3
U26
U8-9
VR3
U2
Manufacturer Part Number
ST MICRO M29W040B120K6
TI 74LVC14AD
IDT IDT74FCT3244APY
EPSON MA505 24.576M-C2
CYPRESS CY7C64603-128NC
FAIRCHILD MMBT4401
PHILIPS 74LVC00AD
MICROCHIP 24LC00-SN
CYPRESS CY7C1019BV33-12VC
ANALOG
AD8532AR
DEVICES
TI SN74AHC1G02DBVR
TI SN74LV164AD
CYPRESS CY7C4201V-15AC
DIG01 300-6027-ND
TI SN74AHC1G00DBVR
MICRON MT58L64L32FT-10
LINEAR TECH LT1765ES8
SG-8002CA-PCC-
DIGIKEY
ND40.0MHZ
I
