Analog Devices ADSP-21160 EZ-KIT LITE Manual page 51

REF QTY.
2.21K 1/8W 1% 1206
45 3
10uF 16V 10% B
46 4
TANT
1A HSM160J DO-214AA
47 2
SCHOTTKY
22K 100MW 5% 805
48 8
100 100MW 5% 805
49 3
1000 100MHZ 1.5A FER002
50 1
0.06 CHOKE
2A S2A_RECT DO-214AA
51 3
SILICON RECTIFIER
600 100MHZ 500MA 1206
52 8
0.70 BEAD
0.047UF 16V 10% 1206
53 1
270PF 50V 10% 805
54 2
1UF 16V 10% 805
55 9
X7R
470PF 100V 10% 1206
56 6
CERM
30PF 100V 5% 1206
57 2
10 100MW 5% 805
58 1
10UF 25V +80-20% 1210
59 6
Y5V
53.6K 1/10W 1% 805
60 2
10UH 47+/-20 IND001
61 2
10K 31MW 5% RNET8
62 1
0.00 100MW 5% 805
63 7
32.4K 1/10W 1% 805
64 1
102K 1/8W 1% 1206
65 1
1K 1/8W 5% 1206
66 1
10K 1/8W 5% 1206
67 4
100K 1/8W 5% 1206
68 1
20.0K 1/8W 1% 1206
69 1
Description
ADSP-21160 EZ-KIT Lite Evaluation System Manual
Ref. Des
R29, R35, R40
CT1, CT9-10, CT21
D6-7
R16, R24, R27, R85-87, R90-
91
R64, R71, R75
FER9
D1, D4-5
FER1-8
C11
C12, C19
C1-2, C4, C7, C27-28, C37,
C41, C43
C13-16, C20, C23
C17-18
R83
C22, C33, C46-49
R78, R82
L1-2
RN1
R4, R8-12, R89
R77
R81
R38
R13-15, R21
R88
R79
Manufacturer Part Number
AVX CR32-2211F-T
AVX TAJB106K016R
MICRO-SEMI HSM160J
AVX CR21-223J-T
AVX CR21-101J-T
MURATA PLM250S40T1
GENERALSEMI S2A
DIGIKEY 240-1019-1-ND
AVX 12065C473JATME
KEMET C1206C271J5GAC210
MURATA GRM40X7R105K016AL
AVX 12061A471JAT2A
AVX 12061A300JAT2A
DALE CRCW0805-10R0FRT1
MURATA GRM235Y.5V106Z025
PHILIPS 9C08052A5362FKRT/R
TDK SLF7045T-100M1R1-2
CTS 746X101103J
PAN ERJ-6GE10R00V
PHILIPS 9C08052A3242FKRT/R
PHILIPS 9C12063A1023FKRT/R
AVX CR32-102J-T
DALE CRCW1206-1002FRT1
CR1206-1003FTR1
VII
