4.5.1 Expansion Interface (P1, P2, P3)

Three board-to-board connector footprints provide the signals for most of the DSP
peripheral interfaces. Analog Devices does not populate these connectors or
provide any additional support for this interface. See section 4.2.3, for more
information on the Expansion Interface. Contact Samtec for the availability and
pricing of these connectors. For the exact pin-out of these connectors, refer to
APPENDIX B:

Table 4-5: P1, P2, P3 Part Number Information

Part Description
90-Position 0.05" Spacing (P1,
P2, P3)
90-Position 0.05" Spacing
(Through Hole)
90 Position 0.05" Spacing
(Surface Mount)
90-Position 0.05" Spacing (Low
Cost)

4.5.2 Power Connector (P4)

The power connector provides all of the power necessary to operate the EZ-KIT
Lite board.

Table 4-6: P4 Part Number Information

Part Description
2.5mm Power Jack (P4)
7.5V Power Supply
ADSP-21160 EZ-KIT Lite Evaluation System Manual
SCHEMATIC.
Manufacturer
Samtec
Mating Connector
Samtec
Samtec
Samtec
Manufacturer
Switchcraft
Digi-key
Mating Power Supply (shipped with EZ-KIT Lite)
GlobTek
Part Number
SFM-145-01-S-D
TFM-145-x1 Series
TFM-145-x2 Series
TFC-145 Series
Part Number
RAPC712
SC1152-ND
TR9CC2000LCP-Y
4-36
