Board Layout
Table 3-1. Mode Selection Switches
SW3
1
2
3
4
1
2
3
4
CONFIGURATION TYPE 3
SW3
1
2
3
4
CONFIGURATION TYPE 4
3-6
BDMA feature is used to load the first 32 program memory
words from the byte memory space. Program execution is held
8 MODE D = 0
off until all 32 words have been loaded. The ADSP-2189M is
7 MODE C = 0
configured in Host Mode.
(Note: requires additional hardware).
6 MODE B = 1
5 MODE A = 0
8 MODE D = 0
7 MODE C = 1
6 MODE B = 0
5 MODE A = 0
IDMA feature is used to load any internal memory as desired.
Program execution is held off until internal program memory
8 MODE D = 0
location 0 is written to. The ADSP-2189M is configured in
7 MODE C = 1
Host Mode.
6 MODE B = 0
5 MODE A = 1
ADSP-2189M EZ-KIT Lite Evaluation System Manual
has an active pull-down.
IACK
has an active pull-down.
IACK
