Connectors
The signals available on these pins are shown in
pins (2–50) are connected to ground.
Table 3-2. ADSP-2189M Pin Names
P3
Pin Signal Name
Number
1 A0
3 A1/IAD0
5 A2/IAD1
7 A3/IAD2
9 A4/IAD3
11 A5/IAD4
13 A6/IAD5
15 A7/IAD6
17 A8/IAD7
19 A9/IAD8
21 A10/IAD9
23 A11/IAD10
25 A12/IAD11
27 A13/IAD12
29 D0/IAD13
31 D1/IAD14
33 D2/IAD15
35 D3/IACK
37 D4/IS
39 D5/IAL
41 D6/IRD
3-10
P4
Pin
Number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
ADSP-2189M EZ-KIT Lite Evaluation System Manual
Table 3-2. All numbered
P5
Signal Name Pin
Number
WR 1
RD 3
BMS 5
DMS 7
PMS 9
IOMS 11
CMS 13
CLKOUT 15
D8 17
D9 19
D10 21
D11 23
D12 25
D13 27
D14 29
D15 31
D16 33
D17 35
D18 37
D19 39
D20 41
Signal Name
IRQWE/PF4
IRQL0/PF5
IRQL1/PF6
IRQ2/PF7
DT0
TFS0
RFS0
DR0
SCLK0
DT1
TFS1
RFS1
DR1
SCLK1
RESET
PWDACK
BGH
MODE_A/PF0
MODE_B/PF1
PWD
MODE_C/PF2
