2. On the SIP page, enter values for the parameters indicated in
Note
Web Page Item
SIP Settings
Enable SIP Operation
Register with a SIP Server
Use Cisco SRST
Primary SIP Server
Primary SIP User ID
Primary SIP Auth ID
Primary SIP Auth Password
Backup SIP Server 1
Backup SIP User ID 1
Backup SIP Auth ID 1
Backup SIP Auth Password 1
Backup SIP Server 2
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-16. SIP Configuration Parameters
Description
When enabled, the device will transmit, receive, and process SIP
messages according to the configured SIP settings below.
When enabled, the device will attempt to register to the configured SIP
Server(s) on this page. To configure the device to send and receive point-
to-point SIP calls, enable SIP Operation and disable Register with a SIP
Server (see
When enabled, the backup servers are handled according to Cisco SRST
(Survivable Remote Site Telephony). It is required for use in clustered
Cisco Unified Communications Manager topologies.
Enter the SIP server address as an IPv4 address in dotted decimal
notation or a fully qualified domain name. This parameter also becomes
the host portion of the SIP-URI for the device's extension on the primary
SIP server. This field can accept entries of up to 255 characters in length.
Specify the SIP User ID for the Primary SIP Server. This parameter
becomes the user portion of the SIP-URI for the device's extension on the
primary SIP server. Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the Primary SIP Server. This parameter is
required for SIP registration authentication. Enter up to 64 alphanumeric
characters.
Specify the Authenticate Password for the Primary SIP Server. This
parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.
Enter the backup SIP server address as an IPv4 address in dotted
decimal notation or a fully qualified domain name. This parameter also
becomes the host portion of the SIP-URI for the device's extension on the
backup SIP server. This field can accept entries of up to 255 characters in
length.
Specify the SIP User ID for the first backup SIP Server. This parameter
becomes the user portion of the SIP-URI for the device's extension on the
first backup SIP server. Enter up to 64 alphanumeric characters.
Specify the Authenticate ID for the first backup SIP server. This parameter
is required for SIP registration authentication. Enter up to 64 alphanumeric
characters.
Specify the Authenticate Password for the first backup SIP server. This
parameter is required for SIP registration authentication. Enter up to 64
alphanumeric characters.
Enter a second backup SIP server address as an IPv4 address in dotted
decimal notation or a fully qualified domain name. This parameter also
becomes the host portion of the SIP-URI for the device's extension on the
second backup SIP server. This field can accept entries of up to 255
characters in length.
931281B
Singlewire InformaCast Loudspeaker Amplifier (AC-Powered) Setup
Configure the SIP (Session Initiation Protocol) Parameters
) in the following table shows which web page items will be defined
.
Section 2.3.7.2, "Point-to-Point
Table 2-16.
Configuration").
