CyberData 011406 Operation Manual page 56

Web Page Item
Fast Fade
Slow Blink
Fast Blink
Nightringer Call Color
Red
Green
Blue
RTP Settings
RTP Port (even)
Jitter Buffer
Call Disconnection
Terminate Call After Delay
Codec Selection
Force Selected Codec
Codec
Note
Note
Operations Guide
Table 2-16. SIP Configuration Parameters (continued)
Description
Strobe will increase in brightness from 0 to the specified brightness and
back to 0 over the course of about 1.5 seconds during the duration of the
event.
Strobe will blink ON at the specified brightness for one second then OFF
for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five times per
second during the duration of the event.
Select desired color (only one may be chosen).
The red LED value for Nightringer.
The green LED value for Nightringer.
The blue LED value for Nightringer.
Use this button to preview the strobe flashing behavior for the Nightringer
Strobe Settings.
Specify the port number used for the RTP stream after establishing a SIP
call. This port number must be an even number and defaults to 10500.
The supported range is 0-65536. Enter up to 5 digits.
Specify the size of the jitter buffer (in milliseconds) used for SIP calls. Valid
values are 50-1000.
Automatically terminate an active call after a given delay in seconds. A
value of 0 will disable this function. Enter up to 8 digits.
When configured, this option will allow you to force the device to negotiate
for the selected codec. Otherwise, the device will perform codec
negotiation using the default list of supported codecs.
Select the desired codec (only one may be chosen).
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the
web page items. First click on the Toggle Help button, and you will see a
question mark (
mouse pointer to hover over a question mark to see a short description of
a specific web page item.
You must click on the Save button and then the Reboot button for the changes to take
effect.
For specific server configurations, go to the following website address:
http://www.cyberdata.net/connecting-to-ip-pbx-servers/
931281B
Singlewire InformaCast Loudspeaker Amplifier (AC-Powered) Setup
Configure the SIP (Session Initiation Protocol) Parameters
) appear next to some of the web page items. Move the
CyberData Corporation
49
