CyberData 011406 Operation Manual page 62

2. On the Multicast page, enter values for the parameters indicated in
Note
Web Page Item
Enable Multicast Operation
Priority
Address
Port
Name
Buffer
Beep
Relay
Polycom Default Channel
Polycom Priority Channel
Polycom Emergency Channel
Multicast Strobe Settings
Blink Strobe on Multicast
Multicast Strobe Brightness
ADA Compliant
Slow Fade
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-19. Multicast Configuration Parameters
Description
Enables or disables multicast operation.
Indicates the priority for the multicast group. Priority 9 is the
highest (emergency streams). 0 is the lowest (background
music). SIP calls are considered priority 4.5. See
"Assigning Priority"
Enter the multicast IP Address for this multicast group (15
character limit).
Enter the port number for this multicast group (5 character limit
[range can be from 2000 to 65535]).
Note: The multicast ports have to be even values. The webpage
will enforce this restriction.
Assign a descriptive name for this multicast group (25 character
limit).
Device will buffer up to four minutes of audio and then play back
the recording after the multicast stream finishes or after the buffer
is full.
When selected, the device will play a beep before multicast audio
is sent.
When selected, the device will activate a relay before multicast
audio is sent.
When a default Polycom channel/group number is selected, the
device will subscribe to the default channel for one-way group
pages. Group Numbers 1-25 are supported. Or, select Disabled
to disable this channel.
When a priority Polycom channel/group number is selected, the
device will subscribe to the priority channel for one-way group
pages. Group Numbers 1-25 are supported. Or, select Disabled
to disable this channel.
When an emergency Polycom channel/group number is selected,
the device will subscribe to the default channel for one-way group
pages. Group Numbers 1-25 are supported. Or, select Disabled
to disable this channel.
When selected, the Strobe will blink a scene when a multicast is
received.
How bright the strobe will blink on a multicast page. This is the
maximum brightness for "fade" type scenes.
Strobe will blink ON at the specified brightness for 150ms then
OFF for 350ms during the duration of the event.
Strobe will increase in brightness from 0 to the specified
brightness and back to 0 over the course of about 3.5 seconds
during the duration of the event.
931281B
Singlewire InformaCast Loudspeaker Amplifier (AC-Powered) Setup
) in the following table shows which web page items will be defined
.
for more details.
Configure the Multicast Parameters
Table 2-19.
Section 2.3.8.1,
CyberData Corporation
55
