Web Page Item
Relay Pulse Code
Relay Pulse Duration (in seconds)
Relay Activation Code
Relay Deactivation Code
Activate Relay During Ring
Activate Relay During Night Ring
Activate Relay While Call Active
Misc Settings
Device Name
Auto-Answer Incoming Calls
Beep on Init
Beep on Page
Disable HTTPS (NOT recommended)
Two Speakers Connected
RGB Strobe
Operations Guide
Table 2-10. Device Configuration Parameters (continued)
Description
DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
The length of time (in seconds) during which the relay will be activated
when the DTMF Relay Activation Code is detected. Enter up to 5 digits.
Activation code used to activate the relay when entered on a phone
during a SIP call with the device. Relay will be active indefinitely, or until
the DTMF Relay Deactivation code is entered. Activate Relay with DTMF
Code must be enabled. Enter up to 25 digits (* and # are supported).
Code used to deactivate the relay when entered on a phone during a SIP
call with the device. Activate Relay with DTMF Code must be enabled.
Enter up to 25 digits (* and # are supported).
When selected, the relay will be activated for as long as the device is
ringing. When Auto-Answer Incoming Calls is enabled, the device will not
ring and this option does nothing.
When selected, the relay will be activated as long as the Nightringer
extension is ringing.
When selected, the relay will be activated as long as the SIP call is active.
Type the device name. Enter up to 25 characters.
When selected, the device will automatically answer incoming calls.
When
ring tone (corresponds to Ring Tone on the Audiofiles page) out of the
speaker.
Device will play the user-defined "pagetone" audio file when it boots.
Device will play the user defined "pagetone" audio file before playing a
SIP page.
Disables the encrypted connection to the webpage. We do not
recommend disabling HTTPS for security reasons.
Specify if one or two speakers are connected to the paging amplifier. If
only one is connected, ensure that it is wired to the first set of terminal
blocks.
Status of optional RGB Strobe.
Click on the Test Audio button to do an audio test. When the Test Audio
button is pressed, you will hear a voice message for testing the device
audio quality and volume.
Click on the Test Relay button to do a relay test.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
931281B
Singlewire InformaCast Loudspeaker Amplifier (AC-Powered) Setup
Auto-Answer Incoming Calls
Configure the Device
is disabled, the device will play a
