Introduction - Quectel QuecOpen AG525R-GL Hardware Design

1

Introduction

®
QuecOpen is an application solution where the module acts as a main processor. With the development
of communication technology and the ever-changing market demands, more and more customers have
realized the advantages of QuecOpen
greatly valued by customers. With QuecOpen
hardware design will be simplified. Main features of QuecOpen
 Simplifies the development of embedded applications, and shortens product development cycle
 Simplifies circuit design, and reduces product cost
 Decreases the size of terminal products
 Reduces power consumption
Supports remote upgrade of firmware over the air

Improves products' cost-performance ratio, and enhances products' competitiveness

This document, describing AG525R-GL QuecOpen
connected to your applications, informs you of the interface specifications, electrical and mechanical
details, as well as other related information of the module.
With the application notes and user guides provided separately, you can easily use the module to design
and set up mobile applications.
FCC Certification Requirements.
According to the definition of mobile and fixed device is described in Part 2.1091(b), this device is a
mobile device.
And the following conditions must be met:
1. This Modular Approval is limited to OEM installation for mobile and fixed applications only. The antenna
installation and operating configurations of this transmitter, including any applicable source-based time-
averaging duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements
of 2.1091.
2. The EUT is a mobile device; maintain at least a 20 cm separation between the EUT and the user's body
and must not transmit simultaneously with any other antenna or transmitter.
3.A label with the following statements must be attached to the host end product: This device contains
FCC ID: XMR2020AG525RGL.
4.To comply with FCC regulations limiting both maximum RF output power and human exposure to RF
radiation, maximum antenna gain (including cable loss) must not exceed:
❒GSM850:≤8.446dBi
❒GSM1900:≤10.030dBi
❒WCDMA II/ LTE Band 2/7/25/38/41:≤8.000dBi
