Table 13: Pin Definition of UART1 Interface
Pin Name
Pin No.
UART1_CTS
71
UART1_RTS
74
UART1_TXD
70
UART1_RXD
72
Table 14: Pin Definition of BT UART Interface
Pin Name
Pin No.
BT_UART_TXD
59
BT_UART_RXD
63
BT_UART_RTS
61
BT_UART_CTS
62
Table 15: Pin Definition of Debug UART Interface
Pin Name
Pin No.
DBG_TXD
107
DBG_RXD
110
Table 16: Logic Levels of Digital I/O
Parameter
V
IL
V
IH
V
OL
V
OH
AG525R-GL_QuecOpen_Hardware_Design
I/O
Description
DO
UART1 clear to send
DI
UART1 request to send
DO
UART1 transmit
DI
UART1 receive
I/O
Description
DO
BT UART transmit
DI
BT UART receive
DI
BT UART request to send
DO
BT UART clear to send
I/O
Description
DO
Debug UART transmit
DI
Debug UART receive
Min.
-0.3
1.17
0
1.35
Automotive Module Series
AG525R-GL QuecOpen Hardware Design
Comment
1.8 V power domain.
Can be configured to GPIOs.
Comment
1.8 V power domain.
Can be configured to GPIOs
Comment
1.8 V power domain.
1.8 V power domain.
Max.
0.63
2.1
0.45
1.8
Unit
V
V
V
V
55 / 104
