Automotive Module Series
AG525R-GL QuecOpen Hardware Design
6.3. Top and Bottom Views
Figure 42: Top View of the Module
Figure 43: Bottom View of the Module
NOTE
These are renderings of the module. For authentic appearance, see the module received from Quectel.
AG525R-GL_QuecOpen_Hardware_Design
94 / 104
