5.4. Current Consumption

Table 34: Module Current Consumption (25 °C, 3.8 V Power Supply)
Description
OFF state
Sleep state
AG525R-GL_QuecOpen_Hardware_Design
Conditions
Power down
AT+CFUN=0 (USB disconnected)
GSM850 DRX = 2 (USB disconnected)
GSM850 DRX = 5 (USB disconnected)
GSM850 DRX = 5 (USB suspend)
GSM850 DRX = 9 (USB disconnected)
EGSM900 DRX = 2 (USB disconnected)
EGSM900 DRX = 5 (USB disconnected)
EGSM900 DRX = 5 (USB suspend)
EGSM900 DRX = 9 (USB disconnected)
DCS DRX = 2 (USB disconnected)
DCS DRX = 5 (USB disconnected)
DCS DRX = 5 (USB suspend)
DCS DRX = 9 (USB disconnected)
PCS DRX = 2 (USB disconnected)
PCS DRX = 5 (USB disconnected)
PCS DRX = 5 (USB suspend)
PCS DRX = 9 (USB disconnected)
WCDMA PF = 64 (USB disconnected)
WCDMA PF = 64 (USB suspend)
WCDMA PF = 128 (USB disconnected)
Automotive Module Series
AG525R-GL QuecOpen Hardware Design
Typ.
0.021
1.144
3.183
2.128
TBD
1.760
3.160
2.181
TBD
1.868
3.191
2.157
TBD
3.175
3.156
2.154
TBD
3.886
3.295
TBD
2.458
Unit
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
