Table 38: Recommended Thermal Profile Parameters
Factor
Soak Zone
Max slope
Soak time (between A and B: 150°C and 200°C)
Reflow Zone
Max slope
Reflow time (D: over 220°C)
Max temperature
Cooling down slope
Reflow Cycle
Max reflow cycle
7.3. Packaging
The module is packaged in tape and reel carriers. One reel is 10.56 meters long and contains 220
modules. The figures below show the packaging details, measured in mm.
AG525R-GL_QuecOpen_Hardware_Design
Automotive Module Series
AG525R-GL QuecOpen Hardware Design
Recommendation
1–3 °C/s
70–120 s
2–3 °C/s
45–70 s
238–246 °C
-1.5 to -3 °C/s
1
97 / 104
