SMC Networks IP8001 Series Operation Manual page 57

(800) PID constant setting
<(810/820) PID constant of
detail setting>
PID constant setting is possible. Direct direction (Dir) and reverse
direction (ruS) are settable individually. Easy adjusting is also
possible. For adjustment, see "■Improved Controllability".
Although PID constant is automatically adjusted during span
adjustment, direct direction (Dir) and reverse direction (ruS) are
settable individually.
Procedure
1 Hold down the set button (
for 1sec. or
parameter change mode.
Select (Dir) by UP or DOWN button
2
( ). Hold down the set button
or
＋
( ) for 1sec. or longer to start
value change mode.
3 To set proportional
constant) with (811), hold down the
＋
set button (
longer. After values start to flash,
change the value within the range
of 0.001 to 9.999. After changing,
hold down the mode button ( ) for
1sec. or longer to set the value.
4 Press the UP or DOWN button
( ). As setting proportional
or
gain (P constant) in clause 3 above,
set integral time (I constant) within
the range of 0.000 to 9.999 with
(812), and set differential time (D
constant) within the range of 0.000
to 9.999 with (813).
5 Hold down the mode button ( ) for
1sec. or longer
parameter change mode.
6 Press the UP or DOWN button
( ) to select reverse direction
or
(ruS). Hold down the set button
＋
( ) for 1sec. or longer to start
value change mode.
7 Repeat clause 3 to 5 to set PID
constant as setting direct direction
(Dir).
8 Hold down the mode button ( ) for
1sec. or longer. Hold down again
for 1sec. or longer after interval.
56
＋
)
longer to start
gain (P
) for 1sec. or
to return to
LCD display
No.IP8S-OM00009
