Barrier - SMC Networks IP8001 Series Operation Manual

Hazardous area
Positioner
Actuator
Cable gland
Input current
Analog output
Alarm output
Grounding

■Barrier

A user should select a barrier suitable to each function. For an input circuit, use a barrier that is
linear resistance type based on intrinsically safe parameters. SMC verifies operation of 52-IP8001
type smart positioner with the barrier shown on Table 9.
For input current
(for non-HART communication)
For input current
(for HART communication)
For analog output
For alarm output
M20×1.5
Terminal lug
(uses twisted wire of 2.63～6.64mm
Table 9
Manufacturer
PEPPERL+FUCHS Inc.
PEPPERL+FUCHS Inc.
PEPPERL+FUCHS Inc.
PEPPERL+FUCHS Inc.
PEPPERL+FUCHS Inc.
PEPPERL+FUCHS Inc.
Non-hazardous area
Barrier
Option output power supply
Fig. 11
M4 screw for internal
grounding terminal connection
2
)
Fig. 12
Model
KFD2-CD-Ex1.32
KFD2-SCD-Ex1.LK
KCD2-SCD-Ex1
KFD2-STC4-Ex1
KFD2-SOT2-Ex2
KFD2-ST2-Ex2
KFD2-SR2-Ex2.W
17
Controller
Input current
Remark
-
-
-
Transistor output
passive type
Transistor output
active type
Relay output
No.IP8S-OM00009
