SMC Networks IP8001 Series Operation Manual page 36

(700) Valve opening
characteristics setting
Valve opening characteristic can be selected from the following.
(700) = Lin Linear
Y=X
(710) = EP25 Equal percentage 1:25 (R=25)
X-1
Y=(R -0.04)×1/0.96
(720) = EP50 Equal percentage 1:50 (R=50)
X-1
Y=(R -0.02)×1/0.98
(730) = qo25 Quick opening 25:1 (R=25)
-X
Y=(1-R )×1/0.96
(740) = qo50 Quick opening 50:1 (R=50)
-X
Y=(1-R )×1/0.98
User's definition〔11 polygonal line settings〕
(750) = USEr
The default value at shipping is (700) = (Lin) Linear. When user's
definition (USEr) is set, the following 11 data can be set
However, the setting range is between -20.0 and 120.0%.
Definition by user can be set by value (vALU) and operation (ACt).
(750,760) Input current 0% position = 0.0% (Default value)
〃
(751,761)
〃
(752,762)
〃
(753,763)
〃
(754,764)
〃
(755,765)
〃
(756,766)
〃
(757,767)
〃
(758,768)
〃
(759,769)
〃
(75A,76A)
100%
100
Quick opening 50％
0
0
0%
7: Be sure to set all 11 date items. To use forced fully-close / fully-open
(parameter code: 500), set items so that stroke (Y) increases
according to input current (X) increases.
35
10% position = 1.0% (
20% position = 4.0% (
30% position = 9.0% (
40% position = 16.0% (
50% position = 25.0% (
60% position = 36.0% (
70% position = 49.0% (
80% position = 64.0% (
90% position = 81.0% (
100% position = 100.0% (
Linear
User
Equal
percentage 50％
Input current (X)
Fig. 30
*7
.
〃
)
〃
)
〃
)
〃
)
〃
)
〃
)
〃
)
〃
)
〃
)
〃
)
100
100%
