SMC Networks IP8000-0 Series Operation Manual

Electro-pneumatic positioner
Hide thumbs Also See for IP8000-0 Series:
Table of Contents

Advertisement

Quick Links

No. IP80-OM00008-D
ELECTRO-PNEUMATIC POSITIONER
PRODUCT NAME
IP8000-0∗0-∗-X14
IP8100-0∗0-∗-X14
MODEL/ Series
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP8000-0 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SMC Networks IP8000-0 Series

Summary of Contents for SMC Networks IP8000-0 Series

  • Page 1 No. IP80-OM00008-D ELECTRO-PNEUMATIC POSITIONER PRODUCT NAME IP8000-0∗0-∗-X14 IP8100-0∗0-∗-X14 MODEL/ Series...
  • Page 2 INDEX Safety Instruction 1 Outline 2.Specifications 3.Operation principle 3-1 Type IP8000 3-2 Type IP8100 4.Attaching 4-1 Type IP8000 4-2 Type IP8100 5.Piping and Attaching of Internal Feedback Unit 6.Electrical Wiring 7.Adjustment 7-1 Zero-point adjustment and span adjustment 7-2 Sensitivity adjustment 7-3 Manual switching 8.Maintenance and Check 9.Caution on Handling...

  • Page 3: Safety Instructions

    Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) and other safety regulations.

  • Page 4: Limited Warranty And Disclaimer/Compliance Requirements

    Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
  • Page 5 1. Outline IP8*00 Series electro-pneumatic positioner controls the motion of actuator by the operation of pilot valve. This pilot valve is activated by signal current from adjustment unit mounted to air cylinder. Specials of “-X14” received the certification of “Intrinsically safe explosion proof conforming with ATEX directive (Ex ib CT5/T6 Gb ) ”...

  • Page 6: Operation Principle

    3. Operation Principle 3-1 Type IP8000 When the input current increases, armature (13) receives counter-clockwise rotating torque with leaf-spring (11) of torque motor (12) functioning as the support, counter-weight (4) is pushed towards left, the space between nozzle (6) and flapper (5) opens and the nozzle back pressure decreases.
  • Page 7 IP8000(lever type feedback) single action positive operation View Stopper screw Automatic/Manual change-over screw (Do not move) (15) Driven diaphragm (Built-in restrictor) OUT2 OUT1 Sensitivity adjusting screw (Adjusts GAIN) Pilot valve Inlet valve A Inlet valve B Feedback lever Span adjusting lever Exhaust EXH.
  • Page 8 3-2 Type IP8100 When the input current increases, armature (14) receives counter-clockwise rotation torque with leaf-spring (12) of torque motor (13) functioning as the support, counter-weight (4) is pushed towards left, the space between nozzle (6) and flapper (5) opens and the nozzle back pressure decreases.
  • Page 9 IP8100(Rotary type cam feedback) double actionpositive operation View X Automatic/Manual change-over screw Stopper screw (Do not move) (Built-in restrictor) OUT2 OUT1 Sensitivity adjusting screw (Adjusts GAIN) Pilot valve Inlet valve A Inlet valve B For reverse position,set by turning over the cam and reversing connections of Exhaust outlets OUT1 and OUT2.
  • Page 10 4. Attaching Warning (1) Make a space needed for maintenance on the setting area. (2) Care so that finger wouldn’t be pinched during mounting and positioning cam. Cut supply pressure and release compressed air in positioner and actuator in advance. Caution (1) Confirm actuator and positioner are connected properly and tightly.
  • Page 11 4-1-2 Connection with external feedback lever Tightening spring (1)Attach to the position that the valve stem and lever Right angle form the right angle when the input signal is Input current 0%(or 100%)position 50%(distribute evenly with 50% input signal set as Input current 50% position the reference).
  • Page 12 4-2-2 Connection with feedback shaft Positioner body (1) Attach to the position at which the positioner feedback shaft and the rotary actuator main shaft alsmost Fork pin unit (P368010-23) concentric (range in which the spring pin of feedback shaft edge enters the hole of Fork lever assembly fork lever assembly shaft edge).
  • Page 13 5. Piping and Attaching of Internal Feedback Unit...

  • Page 15: Electrical Wiring

    Caution Prior to piping, flush enough and remove chip, cutting oil and dust in tube so that obstruction wouldn’t intrude into positioner. Confirm specification and working direction of actuator, and mount pipes and internal feedback unit in accordance with table 2 and 3. 6.
  • Page 16 Warning 1. A positioner must be energized only after wiring via a barrier. 2. Use a linear resistance type barrier based on intrinsically safe parameter for the input circuit. 3. If a positioner is used as intrinsic safety type of explosion protected construction for ATEX, connect it only to the intrinsically safety electric circuit with the following maximum value.
  • Page 17 7. Adjustment Caution (1) For this positioner, span and zero point adjustment of each actuator is necessary. Adjustment shall be done based on each actuator size. (2) Keep in mind that span and zero point adjustment interfere in each other. (3) Characteristics changes due to change of mounting position, ambient temperature and supply pressure.

  • Page 18: Sensitivity Adjustment

    7-1 Zero-point adjustment and span adjustment Table 4 Adjustment procedure (1) Set the input current to 0% (4mADC in the standard (1) Set the input current to 0% (4mADC in the standard specification) and turn the zero adjusting knob by hand to set it specification) and turn the zero adjusting knob by hand to set to the actuator starting point.
  • Page 19 7-2 Sensitivity adjustment SUP=0.4MPa near 4mADC Auto/Manual changeover screw (Built-in restrictor) Stopper screw (Do not move) Sensitivity adjust screw Input current mADC Fig.15 Pilot valve Fig16 Input/output-pressure characteristic Fig.16 shows the input current –output pressure characteristics of OUT1 and OUT2 of the pilot valve.

  • Page 20: Maintenance And Check

    8. Maintenance and Check Warning (1) After installation, repair and disassembling, connect compressed air and perform a proper function test and a leak test. If bleed noise is louder than the initial state or operation is abnormal, stop operation and check if installation is proper or not . And modification of electrical construction is prohibited due to maintaining Explosion-Protected construction function .

  • Page 21: Caution On Handling

    9 Caution on Handling Warning Operation ( 1) Do not use this positioner out of the range of its specifications as this can cause failure. (Refer to 1. Specifications.) (2) If the system is supposed to be in danger because of failure of the positioner, prepare the system with a safety circuit to avoid danger.

  • Page 22: Troubleshooting

    10. Troubleshooting...
  • Page 25 11. Option 11-1 Pilot valve with output throttle Hunching may occur when the positioner is attached to a small capacity actuator. In such a case, use a pilot valve having a throttle for OUT1 and OUT2. The throttle is removable. (Refer to Figs.17 and 18 for mounting and dismounting the throttle.) Table 5 Throttle types Pilot unit No.
  • Page 26 In the case of side attaching, if you use fork lever assembly MX, it is compatible with our IP610 positioner in the attaching size. Also, in the case of backside attaching, if you use fork lever assembly SX, it is compatible with our IP610 positioner in the attaching size. 11-3 External feedback lever ( Type IP8000 ) Levers having different stroke sizes are available for the feedback lever of lever type IP8000.
  • Page 27 11-4 Scale plate unit Caution Locate scale plate with care not to make finger pinched between needle and plate. Adjustment of scale plate Perform adjustment of zero span in positioner before installing the positioner to either face of DA or RA with consideration of operating direction. Refer to Fig. 21. Stop positioner at intermediate opening of actuator (where input signal of 50% finishes to enter to the positioner) and adjust the position of needle to meet with 50 % of scale plate.
  • Page 28 How to order...
  • Page 39 Revision history ’04.06.24 P368010-28,29 P565010-18,19 ’04.11.09 Add the ATEX certificate ’08.07.31 EEx Ex, Addition. Add the “-L,-W ” D ’18.3.7 Change of ”Approval No.” 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 http://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer.
