SMC Networks IP8001 Series Operation Manual page 38

(900) Alarm 1 setting
(A00) Alarm 2 setting
Alarm 1 can be selected by setting ON
shipping is OFF. In addition, an alarm can be selected from the
following with ON selected.
Lower limit alarm (Lo)
(910) =
Upper limit alarm (UP)
The default value at shipping is the lower limit alarm (Lo). The
alarm (920) (actuator position range between -20.0 to 120.0%)
can be set. The default value at shipping is (920) = 0.0%.
The setting for alarm 1 will follow the position value (P value).
The input value (S value) will have no influence over the setting.
12: When an alarm is output, which will be indicated on a LCD indicator.
See "■Contents of LCD Display" for detail.
Alarm 2 can be selected by setting ON
shipping is OFF. In addition, an alarm can be selected from the
following with ON selected.
Lower limit alarm (Lo)
(A10) =
Upper limit alarm (UP)
The default value at shipping is the upper limit alarm (UP). The
alarm (A20) (actuator position range between -20.0 to 120.0%)
can be set. The default value at shipping is (A20) = 100.0%.
The setting for alarm 2 will follow the position value (P value).
The input value (S value) will have no influence over the setting.
13: When an alarm is output, which will be indicated on a LCD indicator.
See "■Contents of LCD Display" for detail.
37
*12
or OFF. The default at
*13
or OFF. The default at
No.IP8S-OM00009
