＜(420) Ratio setting＞
Input all valve stroke which is used (incl. over travel), and select
over travel setting side.
Procedure
1 Hold down the set button (
for 1sec. or longer to move on to
parameter change mode.
Select Ratio setting (rAtE) or non
2
zero point / span mode (oFF) by UP
or DOWN button (
3 To select Ratio setting (rAtE) , hold
down the set button(
1sec. or longer to go to value
change mode.
non zero point / span mode (oFF),
hold down the mode button ( ) for
1sec. or longer to set the value.
4 <Hereafter, only when (rAtE) is set>
Select (st FULL) with UP or DOWN
or
button ( ), and hold down the
＋
set button (
longer. After
change all actuator stroke within
0.0 to 999.9mm. Hold down the
mode button (
longer for 2 times with some
interval.
5 After (st USE) is indicated, mode
move on to value change mode
automatically. As stroke setting
(412) of clause 4, set stroke within
0.0 to 999.8mm (60% or more of all
actuator stroke). After changing,
hold down the mode button ( ) for
1sec. or longer to set.
6 Press UP or DOWN button (
to select over travel setting side (st
SidE), then, hold down the set
＋
button ( ) for 1sec. or longer.
7 Select 0% or 100% side with UP or
DOWN button. Hold down the
mode button ( ) after selection for
1sec. or longer to set.
8 Hold down the mode button ( ) for
1sec. or longer. Hold down again
for 1sec. or longer after interval.
45
＋
)
).
or
＋
) for
When selecting
) for 1sec. or
values flashing,
) for 1 sec. or
)
or
LCD display
