AK-CC55 Single Coil and Single Coil UI

Operation

The controller can be operated in different ways depending on the user interface.
The following options are available:
• Via data commmunication
• Via AK-UI55 Setting Display
• Via AK-UI55 Bluetooth display

Operation via data communication

Via system manager's display
All AK-CC55 controllers can be operated from a central location, e.g. AK-SM 800.
Data communication is to take place via MODBUS or Lon.
Via system manager and service tool
Operation can also be performed from a central location with PC software "Service Tool" connected to a system
manager AK-SM 720 via MODBUS or Lon.
Programming via KoolProg
Programming by use of PC software type KoolProg® via interface MMIMYK connected to RJ12 display connector.

Direct operation

Operation via AK-UI55 setting display
The display can be located on the front of the controller or at a distance of up to 100 metres from the controller.
Smart phone and app via AK-UI55 Bluetooth display
The "AK-CC55 connect" app is used for smart phone operation.
AK-CC55 connect can be downloaded freely to a compatible iOS/Android smartphone device.
The display can be placed at a distance of up to 100 metres from the controller.
Menu operation is established by activating Bluetooth communication to the app.

Operation via AK-UI55 Set

Display AK-UI55 Set
The values will be shown with three digits, and with a setting you can determine whether the temperature is to be
shown in °C or in °F.
The keyboard can be locked and unlocked by pressing arrow up and down at the same time if the parameter P89
has enabled this feature.
