AK-CC55 Single Coil and Single Coil UI

Miscellaneous

Table 41: Miscellaneous → Access codes
Function Description
Access code 3 Access code for local display
Access code 2 Access code for local display
Access code 1 Access code for local display
Table 42: Miscellaneous → Network
Function Description
Network status Quality of the network communication
Network address Network address of the controller
Baudrate Communication speed of network
Parity and stop bit Select parity and stop bit of Modbus messages
Table 43: Miscellaneous → Sensor adjustment
Function Description
S3 Air ON evap. A - Correction of sensor signal e.g. due to long sensor ca-
Adjustment ble
S4 Air OFF evap. A - Correction of sensor signal e.g. due to long sensor ca-
Adjustment ble
S3 Air ON evap. B - Correction of sensor signal e.g. due to long sensor ca-
Adjustment ble
S6 product temp. - Correction of sensor signal e.g. due to long sensor ca-
Adjustment ble
Table 44: Miscellaneous → Factory reset
Function Description
Reset to factory set- Command which will revert all controller settings to
tings factory values.
Make new factory With this command you save the controller's actual
settings as a new basic setting (the earlier factory set-
tings are overwritten).

Advanced

Table 45: Advanced → Advanced injection control
Function Description
Superheat ctrl. Select how to control the superheat of the evapora-
mode A tor. At adaptive control the superheat reference is
adapted automatically to give the best utilization of
the evaporator surface. At load based control the su-
perheat reference is increased at high loads
Superheat close A Minimum superheat limit where the valve is closing
AFidentForce A Expert setting - contact Danfoss for further informa-
tion
Superheat Kp min. A Min limit for amplification factor of the PI controller
adjusting the valve opening degree (expert setting)
Superheat Kp max. Max limit for amplification factor of the PI controller
A adjusting the valve opening degree (expert setting)
Superheat Tn A Integration time of the PI controller adjusting the
valve opening degree (expert setting)
Te feedback gain A Gain factor for feedback of evaporating temperature
signal Te to the PI controller controlling the superheat
(expert setting)
Kp MTR control A Amplification factor for modulating temperature con-
trol (Expert setting)
Tn MTR control A Integration time for modulating temperature control
(Expert setting)
AFident A Expert readout - contact Danfoss for further informa-
tion
Calculated Max OD Calculated maximum opening degree of the injection
A valve (expert readout)
© Danfoss | Climate Solutions | 2021.02
Values
Values
1=Auto, 2=9600 Baud, 3=19200 Baud, 4=38400 Baud x96
0=None, 1=Even, 2=Odd
Values
Values
0=OFF, 1=ON
0=OFF, 1=ON
Values
1=Adaptive, 2=Load based
Code Short name
o05 o05 Acc. code 3
o64 o64 Acc. code 2
P88 P88 Acc. code 1
Code Short name
U45 U45 Comm. status
o03 o03 Unit addr.
--- Bus baudrate
x97 --- Parity bit
Code Short name
r10 r10 Adjust S3
r09 r09 Adjust S4
r53 r53 Adjust S3 B
r59 r59 Adjust S6
Code Short name
z06 --- Reset factory
o67 o67 Make factory
Code Short name
n21 n21 SH mode
x68 --- SH close
x69 --- AFidentForce
x70 --- SH Kp min
x71 --- SH Kp max
x72 --- SH Tn
x73 --- Te-gain
x77 --- MTR Kpfactor
x78 --- MTR Tn sec
x79 --- AFident
x80 --- Max OD %
