AK-CC55 Single Coil and Single Coil UI
Function Description
Display air S4% Signal to the display sensor. Here you have to define
the ratio between the sensors which the display has
to use. S3, S4 or a combination of the two. With set-
ting 0% only S3 is used. With 100% only S4 is used
Display readout ad- Correction of the display´s temperature.If the temper-
justment ature at the products and the temperature received
by the controller are not identical, an offset adjust-
ment of the display temperature can be carried out.
Temperature unit Select whether temperatures are to be shown as °C or
as °F.
Display lock With this setting it is possible to lock the keypad op-
eration of the local display. When not used for some
time, the local display will lock the button operations
and a special key combination is required in order to
use the keypad

Alarm relay priorities

Table 40: Alarm relay priorities
Function Description
Alarm relay Actual status of output function
Alarm relay priority Set which alarm priorities that are to activate the
alarm relay: 0=Not used, alarm relay is not used1:
High. Alarm with high priority will activate relay2: Me-
dium. Alarms with high or medium priority will acti-
vate the alarm relay3: All. All alarms will activate alarm
relay
Mute alarm When muting alarms, the alarm relay will stop signal-
ling the alarm until a new alarm arises
High temperature - Select the priority of the alarms associated to the
Priority alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Low temperature - Select the priority of the alarms associated to the
Priority alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Sensor errors - Prior- Select the priority of the alarms associated to the
ity alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
DI alarms - Priority Select the priority of the alarms associated to the
alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Defrost - Priority Select the priority of the alarms associated to the
alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Miscellaneous - Pri- Select the priority of the alarms associated to the
ority alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Injection - Priority Select the priority of the alarms associated to the
alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Control stopped - Select the priority of the alarms associated to the
Priority alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Leak detection - Pri- Select the priority of the alarms associated to the
ority alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
Humidity ctrl. - Prior- Select the priority of the alarms associated to the
ity alarm group. Be aware - by selecting "Disable" the
alarms will not be shown on the display or be routed
to the alarm relay or to the network.
© Danfoss | Climate Solutions | 2021.02
Values
0=Celsius, 1=Fahrenheit
0=OFF, 1=ON
Values
0=OFF, 1=ON
0=Not used, 1=High Priority, 2=Medium priority,
3=All
0=OFF, 1=ON
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
0=Disabled, 3=Low, 2=Medium, 1=High
Code Short name
o17 o17 Disp. S4 %
r04 r04 Disp. Adj. K
r05 r05 Temp.unit
P89 P89 LockDispKey
Code Short name
u62 u62 Alarm relay
P41 P41 Al.Rel.Prio
q38 q38 Mute Alarm
q28 q28 Hi Temp Prio
q29 q29 Lo Temp Prio
q30 q30 Sensor Prio
q31 q31 DIAlarm Prio
q32 q32 Defrost Prio
q33 q33 Misc Prio
q34 q34 Inject Prio
q35 q35 CtrlOFF Prio
q36 q36 Leak Prio
q37 q37 Humid Prio
