AK-CC55 Single Coil and Single Coil UI

Product specification

Technical data

Electrical specifications

Table 50: Electrical specifications
Electrical data
Supply voltage AC [V]
Voltage variation range max. [V]
Power consumption [VA]
Power ON indicator
Electrical cable dimensioning [mm 2

Sensor and measuring data

Table 51: Sensor and measuring data
Sensor and measuring data
Sensor S2, S6
Sensor S3, S4, S5
Temperature measuring accuracy
Pt1000 sensor specification
Pe measuring
RH measuring

Input and output relay specifications

Table 52: Input and output relay specifications
Input and output relay specifications
Digital input
Digital input
Solid state output
Relays
Analogue output/ PWM
© Danfoss | Climate Solutions | 2021.02
Value
115 V / 230 V, 50/60 Hz
85 – 265 V
5 VA
Green LED
] Max.1.5 mm 2 multi-core cable
Value
Pt 1000 AKS11
Pt 1000 AKS11
PTC 1000 EKS111
NTC5K EKS211
NTC10K EKS221 sensor
(All 3 must be of the same type)
Pt1000: -60 – 120 °C. ±0.5 K
PTC1000: -60 – 80 °C. ±0.5 K
NTC5K: -40 – 80 °C. ±1.0 K
NTC10K: -40 – 120 °C. ±1.0 K
±0.3 K at 0 °C
±0.005 K per degree
AKS 32R Ratiometric pressure transmitter: 10-90%
0 – 10 V
Ri > 10K ohm
Accuracy +/- 0,3% FS
Input/output
DI1
DI2
DI3
DO1 (for AKV coil)
DO2
DO3
DO4
DO5
DO6
AO1
Description
Signal from dry contact functions
Requirements to contacts: Gold plating
Cable length must be max. 15 m
Use auxiliary relays when the cable is longer
Open loop: 12 V
Contact 3.5 mA
115 V / 230 V AC
115V / 230 V AC
Max. 0.5 A
Max. 1 x 20 W AKV for 115 V AC
2 x 20 W AKV for 230 V AC
Note: 2 EC coils are not supported.
115 V / 230 V AC
Load max.: CE. 8 (6)A
UL. 8A res. 3FLA 18LRA
Load min.: 1VA
Inrush: DO5 DO6 TV-5 80A
0 / 10 V Pulse Width Modulated
(PWM) max. 15 mA.
0 – 10 V variable, max. 2 mA
