AK-CC55 Single Coil and Single Coil UI

AK-CC55 connect menu (SW ver. 1.5x)

Start / Stop

Table 27: Start/Stop
Function Description
Main switch Start / stop of refrigeration. With this setting refrigera-
tion can be started, stopped or a manual override of
the outputs can be allowed. (For manual control the
value is set at -1). Then the outputs can be force con-
trolled. Start / stop of refrigeration can also be accom-
plished with the external switch function connected
to a DI input.Stopped control will give a "Main switch
OFF" alarm.
Delay of outputs at Delay of output signal after start-up After start-up or
power-up a power failure the controller's functions can be de-
layed so that overloading of the electricity supply
network is avoided. Here you can set the time delay.

Configuration

Table 28: Configuration
Function Description
Main switch Start / stop of refrigeration. With this setting refrigera-
tion can be started, stopped or a manual override of
the outputs can be allowed. (For manual control the
value is set at -1). Then the outputs can be force con-
trolled. Start / stop of refrigeration can also be accom-
plished with the external switch function connected
to a DI input.Stopped control will give a "Main switch
OFF" alarm.
Application mode Selection of application The controller covers several
applications for control of a refrigerated case. Here
you set which of the possible applications is re-
quired.This menu can only be set when regulation is
stopped, i.e. "r12 Main Switch" is set to 0.
DO2 Configuration Select the function of the digital output
DO3 Configuration Select the function of the digital output
DO4 Configuration Select the function of the digital output
DO5 Configuration Select the function of the digital output
DO6 Configuration Select the function of the digital output
AO1 Configuration Select the function of the analogue output
AO1 Min. voltage Minimum voltage signal of the analogue output
AO1 Max. voltage Maximum voltage signal of the analogue output
DI1 Configuration Select the function of the digital input
DI2 Configuration Select the function of the digital input
© Danfoss | Climate Solutions | 2021.02
Values
-1=Manual, 0=Stop, 1=Start
Values
-1=Manual, 0=Stop, 1=Start
1=1. Comp/Alarm/Light, 2=2. Comp/Rail/Light, 3=3.
Comp/Alarm/Rail, 4=4. Alarm/Rail/Light, 5=5. Hot gas
remote, 6=6. Dual with 1 evap., 7=7. Dual with 2
evap., 8=8. Cold room, 9=9. Custom
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Fans, 2=Fan ECO, 3=Defrost, 4=Rail heat,
5=Alarm, 6=Light, 7=Blinds, 8=Compressor/LLSV,
9=Compressor 2, 10=Air heater
0=None, 1=Rail heat PWM, 2=Valve driver
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
12=Open blinds, 13=Coordinated defrost, 14=Forced
closing, 15=Shutdown, 16=Light control, 20=Leak de-
tection, 21=Adaptive liquid control, 22=Valve driver,
23=Fan alarm
0=None, 1=DI status, 2=Door function, 3=Door alarm,
4=Defrost start, 5=Main switch, 6=Night setback,
7=Thermostat band, 8=Alarm at closed, 9=Alarm at
open, 10=Case cleaning, 11=Forced cooling,
12=Open blinds, 13=Coordinated defrost, 14=Forced
closing, 15=Shutdown, 16=Light control, 20=Leak de-
tection, 21=Adaptive liquid control, 22=Valve driver,
23=Fan alarm
Code Short name
r12 r12 Main switch
o01 o01 DelayOfOutp.
Code Short name
r12 r12 Main switch
o61 o61 Appl. mode
q02 q02 DO2 Config.
q03 q03 DO3 Config.
q04 q04 DO4 Config.
q05 q05 DO5 Config.
q06 q06 DO6 Config.
q09 q09 AO1 Config.
o27 o27 AO1 Min volt
o28 o28 AO1 Max volt
o02 o02 DI1 Config.
o37 o37 DI2 Config.
