Using The Service Locks

General Information
Brainlab recommends locking Robotics Vero with the Service Locks if the device is not being
used for a long period of time or being put out of service.
How to Use the Service Locks
Steps
1.
2.
Hardware User Guide Rev. 1.1 Robotics Vero Ver. 2.1
Move the Imaging Couch Top to the Home Position, e.g. by using the Robotics Service
Application (see Page 27).
Depending on the treatment couch setup, the Home Position may differ from the fixed
co-ordinate system (index -f) of the treatment room. However, the upper plate and base
plate of Robotics Vero must be parallel to each other.
Turn both Service Locks to the LOCKED position.
