Brainlab ROBOTICS VERO Hardware User's Manual page 30

Operating Robotics Vero
Steps
5.
6.
7.
Cancelling a Maneuver
Step
To cancel a maneuver, click Stop at the top of the application window.
Automatic Cancellation
If a maneuver request is not confirmed within three minutes, the request is canceled automatically.
To proceed with the maneuver, pre-select the movement again and continue.
Similarly, if an executed movement is paused by releasing the confirmation push button for more
than three minutes before the final destination is reached, the requested maneuver is cancelled.
30
Robotics Vero is now set up to perform the desired maneuver. Enable the movement by
pressing both buttons on the confirmation device. Depending on the control position this
may be the ExacTrac Vero hand pendant or the ExacTrac Vero control panel. Robotics
Vero will continue moving towards the target while both buttons are held pressed. Re-
lease the buttons to halt the movement.
NOTE: The system parts pictured and described are samples only and may differ in ap-
pearance.
When the maneuver is started the yellow circle moves within the grid according to the ac-
tual position of Robotics Vero. The application displays Moving at the top of the window.
When the maneuver has finished, and the target position has been achieved, the blue
and the yellow circle in the position grid combine to form a green circle at the target posi-
tion. The application displays Position reached at the top of the window.
Hardware User Guide Rev. 1.1 Robotics Vero Ver. 2.1
