Maintaining the System
2.5.2

Auxiliary Power Supply For Brake Release

General Information
Power Input
Protection class
Charger
No.
①
②
NOTE: Country-specific power cable provided.
NOTE: Do not position the Auxiliary Power Supply so that it is difficult to disconnect it from
supply mains. Make sure that no heavy or large items hinder you from disconnecting the main
supply cord from the mains wall socket.
Safety Notes
Use only the Power Supply provided by Brainlab with Robotics Vero. Use this Power
Supply only for operation of Robotics Vero.
Usage and connection of components other than those as specified by Brainlab for that
purpose may lead to exceeding leakage currents or other damage of the equipment and
hereby cause danger to patient or user!
In case of disregarding the restriction as stated above, any operator who connects
components other than those as specified by Brainlab for that purpose creates a medical
electrical system according the definitions of IEC 60601-1-1. The operator assumes
unlimited responsibility for the safe operation of this system!
42
100 Vac - 240 Vac / 47Hz - 63 Hz / 1.5 - 0.7 A
II
Component
Power Output Plug
Power Input Socket
Figure 10
Comment
Connects to Robotics Vero
Type IEC C8
Hardware User Guide Rev. 1.1 Robotics Vero Ver. 2.1
①
②
